Line Tester Click Marked Cross Tester Mobile Phone Button Mark Lineation Life Test Machine
Dongguan Hongjin Test Instrument Co., Ltd.- After-sales Service：Lifetime Maintenance
- Warranty：1 Year
- Max Diameter of Workpiece：<500mm
- Type：Key Life Testing Machine
- Accuracy Grade：0.5
- Load Way：Electronic Load
Base Info
- Model NO.：HJ-66
- Weight：0-100Kg
- Power Source：AC220V
- Testing Sample：2
- Moving Distance：X Axis: 90mm; Y Axis: 150mm
- Moving Speed：16~120 mm,Sec
- Click Speed：0-180 Times,Min
- Motor Torque：1.3n.M
- Line Trace：Rectangle, Triangle, Line, Diagonal
- Transport Package：Fumigation-Free Standard Export Wooden Box
- Trademark：Hongjin
- Origin：China
- Production Capacity：1000 Sets, Month
Description
Basic Info.
Model NO. HJ-66 Weight 0-100Kg Power Source AC220V Testing Sample 2 Moving Distance X Axis: 90mm; Y Axis: 150mm Moving Speed 16~120 mm/Sec Click Speed 0-180 Times/Min Motor Torque 1.3n.M Line Trace Rectangle, Triangle, Line, Diagonal Transport Package Fumigation-Free Standard Export Wooden Box Trademark Hongjin Origin China Production Capacity 1000 Sets/ MonthProduct Description
This machine is mainly used for mobile phone touch screen click, scribing life test, PLC control, touch screen display, with automatic memory of times, power-down memory, click force pressure control, accumulation of life times, and automatic shutdown when the set times are reached. Using motion trajectory test, convenient coordinate finding function, you only need to take two points on the LCD screen of the mobile phone to draw a line, three points to generate a triangle, and four points to generate a square or rectangular motion trajectory. Test the mobile phone specification to access the motion track for the next call. And the use of stepping motor with linear guide and ball screw as the moving mechanism, accurate positioning, high precision, low noise, precision and durability.| Testing sample | 2 |
| Moving distance | X axis: 90mm; Y axis: 150mm |
| Moving speed | 16~120 mm/sec |
| Click speed | 0-180 times/min |
| Counter | 6-digit counting, with power-down memory function |
| Way to control | PLC controller and touch screen display |
| Cylinder | SMC brand, 100~ 500gf force adjustable |
| Standard weight | 50g 100g each two |
| Motor torque | 1.3N.m |
| Line trace | Rectangle, triangle, line, diagonal |
| Machine size | W550xD550xH510 |
| Power supply | 220V/3A |
| Machine weight | About 35kg |
| Dimensions | W550*D600*H450 (mm) |
