50kV/5kVA Manual AC/DC Hipot Test Set (Pointer Type) GDYD-55M

HV Hipot Electric Co., Ltd.
  • Type：Withstand Voltage Test Set
  • Accuracy Grade：1.5%
  • Load Way：Electronic Load
  • Display：Pointer type
  • Control：Manual Control
  • Weight：0-100Kg

Base Info

  • Model NO.：GDYD-55M
  • Power Source：AC220V
  • Oil Cylinder Position：NO
  • Input：AC220V ± 10%
  • Frequency：50Hz,60Hz ± 1Hz
  • Output：0-50kV, AC RMS
  • Capacity：5kVA (based on selectable)
  • HT Source：Epoxy resin cast HT transformer (Dry type testing
  • Output control：Manual control
  • Voltage accuracy：≤1.5% (F.S)
  • Current Accuracy：≤1.5% (F.S)
  • Transport Package：Wooden Case
  • Trademark：HV HIPOT
  • Origin：Wuhan China
  • Production Capacity：5000sets,Year

Description

Basic Info.

Model NO. GDYD-55M Power Source AC220V Oil Cylinder Position NO Input AC220V ± 10% Frequency 50Hz/60Hz ± 1Hz Output 0-50kV, AC RMS Capacity 5kVA (based on selectable) HT Source Epoxy resin cast HT transformer (Dry type testing Output control Manual control Voltage accuracy ≤1.5% (F.S) Current Accuracy ≤1.5% (F.S) Transport Package Wooden Case Trademark HV HIPOT Origin Wuhan China Production Capacity 5000sets/Year

Product Description

50kV/5kVA Manual AC/DC Hipot Test Set (Pointer Type) GDYD-55M

Specifications

InputAC220V ± 10%
Frequency50Hz/60Hz ± 1Hz
Output0-50kV, AC RMS
Working Duration100%Rated-1minute, 50%-continuous
Capacity5kVA (based on selectable)
HT SourceEpoxy resin cast HT transformer (Dry type testing transformer)
Output controlManual control
Voltage accuracy< 1.5% (F.S)
Current Accuracy< 1.5% (F.S)
Timing range0-99H
MeteringDigital display, kV meter: AC 0-50kV, mA meter: AC 0-100mA
Humidity85% RH
Environmental temperature-20ºC~50ºC
Weight of Control unitabout 20kg
Dry testing transformerabout 45kg
