• Model NO.：GD-4136L,H
• Customized：Non-Customized
• Color：Yellow
• Power Supply：AC 220V; 50Hz
• Output voltage：DC 0~16kV,0-32kV (adjustable)
• Max.energy：1024J,8UF,2048J, 4UF
• DC flashover voltage：16KV,32kV
• Max. testing distance：100km
• LV impulse transmitting voltage：30V
• Transport Package：Wooden Case
• Specification：ISO, SGS
• Trademark：HV Hipot
• Origin：China
• HS Code：9030332000
• Production Capacity：1000PCS,Year

Basic Info.

Model NO. GD-4136L/H Customized Non-Customized Color Yellow Power Supply AC 220V; 50Hz Output voltage DC 0~16kV/0-32kV (adjustable) Max.energy 1024J,8UF/2048J, 4UF DC flashover voltage 16KV/32kV Max. testing distance 100km LV impulse transmitting voltage 30V Transport Package Wooden Case Specification ISO, SGS Trademark HV Hipot Origin China HS Code 9030332000 Production Capacity 1000PCS/Year

Product Description

General introduction

GD-4136L/H Cable Fault System is important tool to maintain all kinds of cables. It uses various detection way to test cable faults, which is suitable for different levels voltage power cables and communication cables.

The system contains below units:

• GD-2131L/H Impulse Generator
• GD4132 Cable Fault Locator
• GD-4133 Multi-pulse Cable Fault Tester
• GD-4133S Multiple Pulse Coupler

GD-2131L/H Impulse Generator is used to generate HV impulse when using impulse flashover method to detect high impedance fault.

GD4132 Cable Fault Locator main function is to locate poor insulation point, to detect circuit and depth of power cable.

GD-4133 Multi-pulse Cable Fault Tester is used to measure distance between cable faults. It is easy to operate and with friendly interface.

GD-4133S supplied pulse coupling signal for GD-4133 and isolate it from high voltage equipment.
