Transformer Tap Changer Tester
Sansion Power Electric Co., Ltd.- Type：Universal Testing Machine
- Maxcapacity：<1000KN
- Accuracy Grade：0.5
- Load Way：Electronic Load
- Loading Method：Dynamic Load
- Display：LCD
Base Info
- Model NO.：SXYZ-3000
- Control：Manual Control
- Weight：0-100Kg
- Power Source：AC 110V,220V at Customized
- Oil Cylinder Position：Under
- Resistance Measuring Range：0.3~40 Ohm
- Transport Package：Plywood Case
- Specification：ISO9001 SGS
- Trademark：Sansion
- Origin：Wuhan, China
- HS Code：9030820000
- Production Capacity：100 Units
Description
Voltage Output
>20V
Working Supply
AC220V±10%,50Hz
Current Output
≥1A
Power
180W
Resistance Measuring Range
0.3~40Ω
Resistance Measuring Precision
0.1Ω~1Ω±0.1Ω,1Ω~40Ω±5%
(exclude1Ω)
Time Measuring Range
1ms~256ms
Time Measuring Recision
1ms~100ms±0.1ms
100ms~250ms±1%
3 Phase Synchronism
0.1ms
Sampling Rate
10~20KHz
Working Temperature
0~40ºC
Working Humidity
≤80%RH
More information, please kindly contact with us, we can customize the suitable test set according your requirements and give you the best quotation. Thank you!
