GDJB-II Single Phase Relay Protection Tester
HV Hipot Electric Co., Ltd.- Power Supply：AC 220V+,-10%, 50Hz
- Working Environment：Temperature -10--40centigrade
- Humidity：<=85%
- Atmosphere：86-106kpa
- Output Power Supply：AC Voltage: 0-220V,3A
- AC Current：0-100A,7.5V , customized
Base Info
- Model NO.：GDJB-II
- Transport Package：Carton or Wooden Case
- Specification：ISO, SGS
- Trademark：HV Hipot
- Origin：China
- HS Code：9030820000
- Production Capacity：2000PCS,Year
Description
AC voltage
0-220V/3A
AC current
0-100A/7.5V (200A can be customized)
0-20A/25V
0-5A/5V
DC voltage
0-220V/3A
DC current
0-20A/25V
Fixed voltage output
DC 24V/48V/110V/220V
C. Performance Index
Ammeter and voltmeter: 4 1/2 digit.
Digital millisecond meter: 0-99.9999s
D. Functions
1. Measure relay: Measure start value, return value and drop-off to pick-up ratio of current, voltage relay.
2. Time relay: Measure start value, return value and action time.
3. Intermediate relay: Measure all kinds of coil with start. Remain start value, return value, holding value and action time of coil intermediate relay.
4. Reclosing relay: Charge test of capacitance, charge time, reclosing time and middle components test.
5. Differential relay: DC Excitation test, Braking test, Volt-ampere characteristic test.
6. Other unconventional relays and LV circuit breakers.
