• Model NO.：SXZRS Series
• Control：Computer Control
• Weight：0-100Kg
• Power Source：AC 110V,220V at Customized
• Oil Cylinder Position：Under
• Current Range：Customized
• Power Supply：AC220V±10%  50±1Hz
• Transport Package：Plywood Case
• Specification：ISO9001 SGS
• Trademark：Sansion
• Origin：Wuhan, China
• HS Code：9030332000
• Production Capacity：100 Units

Basic Info.

Model NO. SXZRS Series Control Computer Control Weight 0-100Kg Power Source AC 110V/220V at Customized Oil Cylinder Position Under Current Range Customized Power Supply AC220V±10%  50±1Hz Transport Package Plywood Case Specification ISO9001 SGS Trademark Sansion Origin Wuhan, China HS Code 9030332000 Production Capacity 100 Units

Product Description

General information:

Also called: DC Resistance Meter, DC Meter, Transformer DC Resistance Tester, Inductive Load DC Resistance Tester.

SXZRS Series DC Winding Resistance Tester (Three Phases) is applied for DC resistance three phases measuring synchronously of large capacity transformer winding. It is also can regulate and tap connect the load regulating transformer directly without discharging.

Features:
√  Small size, light weight.
√  English interface, easy to operate.
√  Measuring fast and accurately.
√  Auto discharging and indicating, safe and reliable.
√  The neutral outgoing winding test at Y connection, the tester can adopt three phase synchronous measurement method, to test the DC resistance of A0, B0, and C0.
√  Counter potential protecting function.
√  500 groups' storage.
√  Large LCD screen, build-in printer.

Specifications:
√    Output current (Current range is at your customized):
      Three phase test: 2*10A, 2*5A, 2*2A
      Single phase test: 20A, 10A, 2A
√    Measuring rage:
      2*10A:500μΩ~500mΩ
      2*5A: 1mΩ~1Ω
      2*2A: 2.5mΩ~2.5Ω
      20A:  250μΩ~1Ω
      10A:  500μΩ~2Ω
       2A:   2.5mΩ~10Ω
√    Resolution:   0.1μΩ
√    Measuring precision:   ±(0.2%+2digits)
√    Oversize: 420mm×250mm×340mm
√    Weight: 13kg
√    Working condition:  -10ºC~50ºC
√    Environmental humidity:≤85%RH
√    Power supply:AC220V±10%  50±1Hz

Warranty: One year quality guarantee after shipment.
More information, please kindly contact with us, we can customize the suitable test set according your requirements and give you the best quotation. Thank you!
