Rebar location/position detector
Zhuozhou Tianpeng Imp. & Exp. Trade Co., Ltd.- Type：Test and Measurement Instruments
- Transport Package：Standard Export Wooden Box
- Trademark：tianpeng
- Origin：China
Base Info
- Model NO.：GW50
- HS Code：90248000
- Production Capacity：10000 PCS,Year
Description
Item
SPEC
1
Bar diameter application range(mm)
Φ6 - Φ50
2
maximum value permissible error of Bar diameter
≤±1
3
Protective layer thickness measuring range
The first measuring range (mm)
6 - 90
The second measuring range (mm)
7-180
4
The maximum error of reinforced protective layer thickness test value
The first measuring range (mm)
The second measuring range (mm)
6 - 59
7 - 79
≤±1
60 - 69
80 - 119
≤±2
70 -90
120 - 180
≤±4
5
Work environment condition
Work temperature °C
-10 - +40
relative humidity RH
< 90%
6
power supply mode
Alkaline cell X 6
