• Model NO.：HM5002-10A
• Humidity：<90%
• Warranty：1 Year
• Standard：ISO9001 SGS
• Product Name：DC Resistance Test
• Transport Package：Wooden Box with Foam Inside
• Specification：390*205*290mm
• Trademark：GDHM
• Origin：Hubei, China(Mainland)
• Production Capacity：500sets,Month

Basic Info.

Model NO. HM5002-10A Humidity <90% Warranty 1 Year Standard ISO9001 SGS Product Name DC Resistance Test Transport Package Wooden Box with Foam Inside Specification 390*205*290mm Trademark GDHM Origin Hubei, China(Mainland) Production Capacity 500sets/Month

Product Description

Transformer DC winding  Resistance Test Set price made in China

Summary
Transformer dc resistance is transformer manufacturing of semi-finished products, finished products testing, installation, commissioning test and power sector preventive test will measure project, can effectively find the transformer coil material selection, welding, loose connection parts, short, break the blemish such as manufacturing and running after the existence of hidden dangers.In order to meet the needs of transformer dc resistance rapid measurement, it has developed a new generation of CT series dc resistance tester.

The instrument adopts the new program-controlled linear constant current source technology, with large output current, current gear, small volume, light weight, etc.

The machine is controlled by a single-chip microcomputer, automatic complete self-checking, data processing, display, save, print, and other functions, with sophisticated electronic measuring technology, makes the instrument is of high precision and wide measuring range, easy operation, can realize the sensibility of transformer and voltage transformer resistance rapid measurement.

Advantage1.Using high precision electronic measuring technology and high-performance single chip microcomputer, makes the instrument has high measurement precision and numerical stability, good repeatability. 2.Instrument can choose appropriate according to the load current, the current gear, the biggest can output 10A current. 3.With printing, storage, real-time view the data, and other functions.
4. Big screen display, menu operation, friendly interface, be clear at a glance, convenient operation.

5.Micro printer for thermal printer, speed, the surface can be installed directly printing paper.

6.With audible alarm automatic discharge and discharge instructions, and other functions.



DC Power 10A Transformer DC Winding Resistance Tester/ 10A DC Resistance Analyzer

Technical parameter1.Current (auto): 10A, 5A,1A,200mA,40mA,<5mA
2. Test range:
   100Ω-200KΩ   (<5mA)
               1Ω-500Ω     (40mA)
   100mΩ-100Ω    (200mA)
   5mΩ-20Ω (1A)
   1mΩ-4Ω (5A)
    0.5mΩ-2Ω      (10A)
3. Resolution:0.1µΩ
4. Accuracy: :±0.2%
5. Power supply:AC220V±10%,(50±1)HZ
6.Operation condition:-10~50ºC Humidity <90% No condensation.
7.Size:390*205*290mm
8. Weight:10KG
