Digital Direct Shear Apparatus
Shanghai Civil & Road Instrument Co., Ltd.- After-sales Service：24 Hours Online Support
- Warranty：1 Year
- Max Diameter of Workpiece：<500mm
- Mass Scope of Workpiece：<900kg
- Type：Material Testing Machine
- Maxcapacity：1.2kn
Base Info
- Model NO.：STWZJ-2
- Accuracy Grade：1
- Load Way：Electronic Load
- Loading Method：Static Load
- Display：Digital
- Control：Electric
- Weight：250
- Power Source：Can Customized
- Oil Cylinder Position：No
- Area of The Soil Sample：30cm2
- Lever Ratio：1:12
- Vertical Loading：50,100,200,300,400(Kpa)
- Max. Horizontal Loading：1.2kn
- Shear Rate：0.01-6.99mm,Min
- Voltage：AC220V±10%
- Testing Temperature：-20~50c
- Feature：with Heating, Cooling Function When Test Related P
- Transport Package：Wooden Case
- Specification：97x60x121
- Trademark：SHTG
- Origin：China
- HS Code：9031809090
- Production Capacity：100PCS,Month
Description
Basic Info.
Model NO. STWZJ-2 Accuracy Grade 1 Load Way Electronic Load Loading Method Static Load Display Digital Control Electric Weight 250 Power Source Can Customized Oil Cylinder Position No Area of The Soil Sample 30cm2 Lever Ratio 1:12 Vertical Loading 50,100,200,300,400(Kpa) Max. Horizontal Loading 1.2kn Shear Rate 0.01-6.99mm/Min Voltage AC220V±10% Testing Temperature -20~50c Feature with Heating, Cooling Function When Test Related P Transport Package Wooden Case Specification 97x60x121 Trademark SHTG Origin China HS Code 9031809090 Production Capacity 100PCS/MonthProduct Description
STWZJ-2 Digital Direct Shear Apparatus| Area of the soil sample | 30cm2 |
| Lever ratio | 1:12 |
| Vertical loading | 50,100,200,300,400(KPa) |
| Max. Horizontal loading | 1.2kN |
| Shear rate | 0.01-6.99mm/min |
| Voltage | AC220V±10% |
| Testing Temperature | -20~50ºC |
| Feature | With heating, cooling function when test |
