- Model NO.:DH-RTS-100
- After-sale Customer Service:Yes
- OEM Service:Yes
- Transport Package:Standard Exporting Wooden Package
- Trademark:DahoMeter
- Origin:Dongguan, China
- HS Code:9027809900
- Production Capacity:300 Sets,Month
Model | DH-RTS-50 | DH-RTS-80 | DH-RTS-100 | DH-RTS-150 | DH-RTS-200 | DH-RTS-300 | DH-RTS-480 |
Control system | Balanced temperature control system |
Temp.Range | High temperature chamber | +60ºC~+200ºC |
Preheating time | +60ºC~+200ºC About 20 minutes |
Low temperature chamber | A:-55ºC~10ºC;B:-70ºC~10ºC;C:-80ºC~10ºC |
Precooling time | A:+20ºC~-55ºC About 60 minutes |
B:+20ºC~-75ºC About 75 minutes |
C:+20ºC~-80ºC About 90 minutes |
Testing chamber | A:-40ºC~150ºC;B:-55ºC~150ºC;C:-65ºC~150ºC |
Recovery time | High temperature exposure for 30 minutes |
Low temperature exposure for 30 minutes |
Within 5 minutes |
Transferring time | Within 10 seconds |
Temp.fluctuation | ±1.0ºC |
Temp.deviation | ≤±2.0ºC |
Internal dimension(CM) | W | 40 | 50 | 55 | 68 | 68 | 80 | 80 |
H | 40 | 40 | 45 | 45 | 50 | 50 | 55 |
D | 32 | 40 | 40 | 50 | 60 | 75 | 93 |
External dimension(CM) | W | 140 | 150 | 155 | 168 | 168 | 180 | 180 |
H | 185 | 185 | 195 | 195 | 200 | 200 | 205 |
D | 126 | 140 | 140 | 165 | 180 | 195 | 225 |
Testing weight(KG) | 3.5 | 5 | 5 | 5 | 10 | 12 | 15 |
Interior material | SUS#304 stainless steel plate |
Exterior material | Electrostatic sprayed surface treatment steel plate or stainless steel(SUS304) |
Insulation material | High density polyurethane foam and glass fiber |
Refrigeration system | eclipsed type,hermetic type/semienclosed compressor,environmental protection refrigerant(R404a/R23) |
Controller | LCD color touch screen,English displaying,Program,Communicating function |
Protective device | No-fuse switch,compressor overpressure,overheating,overcurrent protection,overtemperature protection,fan overload protection,fuse,dry heating machine protection,fault warning system |
Standard accessories | one pcs of hole(φ5cm).two sets of testing racks,four pcs of moving wheels,two meters of power cord,communication interface |
Power | AC380±10% 50HZ 3 phase wires + ground wires |
Packaging & Shipping:Company Information:We,
Dongguan Hongtuo Instrument Co., Ltd, a China based company, are pleased to introduce ourselves as a notable testing equipments and machines manufacturer.Our company was established in the year 2000 with two primarily motto, which includes complete client satisfaction and to reach top-most position in the international market. The exceptional quality of our products like
Gold Tester,Gold Testing Machine,Density Meter,Universal Tensile Testing Machine,Climatic Chamber,Melt Flow Index Tester,Charpy Impact Testing Machine,Tap Density Tester,Abrasion Tester,Ultrasonic Flaw Detector,Surface Roughness Tester and other Laboratory Testing Equipment, etc. is our company's USP.
