• Model NO.：TD-508C
• HS Code：90248000
• Production Capacity：500sets Per Month

Basic Info.

Model NO. TD-508C HS Code 90248000 Production Capacity 500sets Per Month

Product Description

Model: TD-508C
Power supply: AC 220 V (-5%~+10%), 50 Hz
Measurement range: 2.0 m (±10mm)
Heating type: by an electric heater
Heating power: 3200 W
Bath circulation: by a magnetic circulation pump
Temperature controlling range: 5~50°C; digitally displayed
Temperature controlling accuracy: ±0.1°C
Dragging speed: two grades, 10~50 mm/min,
frequency conversion stepless adjustable
Measurement accuracy: ±1 mm
Ductility display: Controlled by microprocessor;
digitally displayed after data processing
Dragging force measurement range: 0~300 N
Dragging force accuracy: ±1N;
Display resolution: 0.1 N
Data output: 1) Communicate with a computer through a RS232 port
2) Printed out by a micro-printer
Refrigeration type: by a compressor; input power is 800 W
Ambient temperature: -10~+35°C
Relative humidity: ≤85%
Total power consumption: not more than 4000 W
