Ce Approved Quality Stability Climate Test Chamber for Electronic

Guangdong Komeg Industrial Co., Ltd.
  • After-sales Service：24 Hours on Line Services
  • Warranty：12 Months
  • Type：Material Testing Machine
  • Weight：100-500Kg
  • Power Source：AC380V
  • Temp. Range：-70°c~+150°c or -68°f~+302°f

Base Info

  • Model NO.：KMH-64R
  • Humidity Range：20-98%R.H.
  • Temp. Constancy：+,-0.5oc
  • Humidity Constancy：+,-2.5%R.H.
  • Temp. Uniformity：+,-2.0oc
  • Humidity Uniformity：+,-3.0%R.H.
  • Equipment Power：7.5kw
  • Martial：Stainless Steel
  • Transport Package：Strong Plywood Case, Meet International Standards
  • Specification：Standard and customs made
  • Trademark：KOMEG
  • Origin：Dongguan, China
  • HS Code：90321000
  • Production Capacity：1000 Sets Per Year

Description

Environmental Temperature and Humidity ChamberSecifications ( at +20ºC room temp.  Or+25ºC water temp with empty load)ModelKMH-R series64RTemp. range -20ºC~150ºCInterior sizelW(mm)400H(mm)400D(mm)400Exterior sizeW(mm)600H(mm)1526D(mm)1200Power(KW)4.5Weight(KG)150Humidity uniformity±3.0%R.HHeat up time -20ºC~+100ºC,within 35 minPull down time +20ºC~-20ºC, within 45 minStandard accessoriesSight window*1, cable port(portΦ50mm)*1, shelves*2, chamber lamp*1, power cable *2mSafety device  (standard)No fuse breaker, over pressureover heat and over current protection for compressor,Over temp. protect, over load protect of blower, dry heat protectionControl SystemBalanced Temperature & Humidity Control SystemRefrigeration systemAir Cooled (Water Cooled Type is option)Hermetic compressor,Single stage refrigeration system                      CFC-Free refrigerant(HFC-507/HFC-23)ControllerPanel:7-inch LCD Touch panel,    Chinese or English display selectableOperation model :Program or fix point runningMemory capacity :120programs,1200steps,All repeat 999 cycles, part repeat 99 cyclesHumidity Range20~98%R.HTemp. constancy±0.5ºC   Humidity constancy±2.5%R.HTemp. uniformity±2.0ºCInterior materialStainless Steel Plate(SUS 304)Exterior materialBaked Painting Steel Or Stainless steel(SUS304)Insulation materialRigid polyurethane Foam and Glass Fiber WoolAmbient Temp.+5ºC~+35ºCWiring methodAC 380±10%50Hz ,3 phase 4 wires +Ground WiresNote: 1. We reserve the right to change specifications without prior notice
2. Customized sizes and configurations available
Features:
a. High-quality appearance, the body adopted an arc shape, surface automobile coating technology processing, and mechanical explosion-proof handle, easy to operate, safe and reliable.

b. Rectangular multi-layer glass View window, the use of guinea pigs observed in the test window with anti-sweat heaters device prevents water gas condensate, knot, water droplets, LED lamps to keep the inside lighting.

c. Door frame with airtight packing, can be effectively isolated from the internal temperature of the leak

d. With external water supply system, convenient to supplement the cylinder water supply, and automatic recovery using.

e. Compressor cycling system used France "Tecumseh" brand which can effectively remove condenser pipe and between capillary Lubricating oil and whole series adopt environmental protection refrigerant (R23, R404, R507)

f. Controller uses the imported LCD display screen, can display measured values (PV) and setting values (SV) time

g. Controller with multi-segment program editor and temperature and humidity can be fast (QUICK) or slope (SLOP) controlled.

h. Built-in mobile wheels allow easy movement and placed, with a strong positioning screw position.

Chamber Structure
Material of outer case:
The housing is processed and formed with high-quality (t=1.2mm) A3 color plates through CNC machine with surface sprayed with plastics, looking smoother and more artistic;
Material of inner case:
Imported high-grade stainless steel (SUS304)
Auxiliary structure
Height of sample shelf can be adjusted as required.
Since designing test equipment according to historical experience, a reasonable air channel circulation system has formed and the temperature inside the chamber can obtain the highest uniformity.
Parallel distance between test specimen and lamp surface:
Reach the irradiance requirements of sample test (the height of test specimen platform is adjustable).
Subsidiary Functions
Temperature controller based on PID actions differentiated by hour
Platinum thermometer measures temperature of dry-bulb temperature, and transmit dry-bulb temperature and the main set valve in the means of continuous communication.
Light source control
Automatically monitor temperature: Irradiatometer is attached to control irradiance by adjusting pressure of lamp through pressure regulator to keep the irradiance at stated level while controlling test time.
Platinum resistance temperature sensor
STT-R series platinum resistance temperature sensor: Introducing stainless steel housing, stuffed with heat conduction materials and sealed with sealing materials, small-sized, highly capable of preventing water and shock of up to IP67.
Temperature signal solid module
Temperature signal solid module SSR is short for Solid State Relay.
New contact-less electronic switch is manufactured with foreign advanced technology and components with high performance
The input end needs small control current only, and is well compatible with various integrated circuits such as TTL, HTL, CMOS and so on.
Ce Approved Quality Stability Climate Test Chamber for ElectronicAfter-serviceIf you face any problems in future during testing process we promise we will give you a reply within 48 hours and solution provide within 3 working days. We can offer operation video and English operation muanual. We can provide video-conference. If customers require on-site service, the transport and travel expense shall be borne by customer.
