• Model NO.：KTS-D Series
• Test. Chamber： -65c~+150c
• High Temp. Chamber： +60c~+200c
• Standard Accessory：Cable Port
• Refrigeration System：Water Cooled
• Power：AC 380;10%50Hz
• Controller：LCD Touch Panel
• Product Name：Thermal Shock Chamber
• Transport Package：Strong Plywood Case, Meet International Standard
• Specification：Standard and Customized
• Trademark：KOMEG
• Origin：Dongguan China
• HS Code：90321000
• Production Capacity：1000 Sets,Year

. Chamber size

Workspace volume: W 1000 × H 1000 × D 800 mm

Exterior size: W 1200 × H 2030 × D 2645 mm (about)

2.Temperature range

-70c to +150c



3.Heating up rate

From -40°C to +85°C, average 15°C/min with load 48KG

4.Cooling down rate

From +85°C down to -40°C, average 15°C/min with  load 48KG

2.Insulation box

wall material: high-quality carbon steel with static color spray

inner wall material: SUS304 # matte stainless steel plate

sulation materials: rigid polyurethane foam insulation layer + glass fiber.

3.DoorSingle door. Heating wire was installed at the door frames to prevent condensation at low temperatures.4. Observation windowObservation window on the door. Multi-layer hollow electro-thermal coating glass can effectively heat insulation and prevent condensation.5. Lighting deviceOne lamp on the observation window6. HeaterHigh-quality nickel-chromium alloy wire electric heater, non-contact control (SRR).
