• Model NO.：SXYZ-II
• Loading Method：Dynamic Load
• Display：LCD
• Control：Manual Control
• Weight：0-100Kg
• Power Source：AC 110V,220V at Customized
• Oil Cylinder Position：Under
• Leakage Current：0-10mA(Extendable)
• Voltage：30-100V(Extendable)
• Working Power Source：AC220V,50Hz
• Transport Package：Plywood
• Specification：ISO9001 SGS
• Trademark：Sansion
• Origin：Wuhan, China
• HS Code：9030820000
• Production Capacity：100 Units

Basic Info.

Model NO. SXYZ-II Loading Method Dynamic Load Display LCD Control Manual Control Weight 0-100Kg Power Source AC 110V/220V at Customized Oil Cylinder Position Under Leakage Current 0-10mA(Extendable) Voltage 30-100V(Extendable) Working Power Source AC220V/50Hz Transport Package Plywood Specification ISO9001 SGS Trademark Sansion Origin Wuhan, China HS Code 9030820000 Production Capacity 100 Units

Product Description

General information:
SXYZ-II Metal Oxide Arrester (MOA) Tester is a preventive on-line/on-site test tool to check the health of Metal Oxide Arresters of different voltage levels. It can detect dangerous problems inside the arresters such as insulation moisture and valve plate aging. It's applied for energized or non-energized MOA detecting of all the voltage levels.

Features:

√   Large LCD screen, English interface, easy to operate.

√   High precision sampling and processing, advanced Fourier harmonic analysis technology, to ensure the test data be more reliable.

√   High speed magnetic isolating sensor to sample the input voltage and current signal directly, and guarantee the reliability and security of data.

√   Continuous testing, the voltage and current curve could be displayed, the test data and curve could be printed out.

√   The anti-interference calculation is available, to compensate the current deviation of A and C phase against B.

√   High speed sampling frequency, advanced digital signal processing technology, high anti-interference ability and precision.

√   Build-in high speed printer

√   Engineering plastics carrycase, dustproof, warterproof and corrosion prevention, it's light and portable.

√   Build-in high capacity rechargeable battery. (Option)

√   RS232 port, to communicate with PC. (Option)

Specifications:

√  Working Power Source:AC220V/50Hz.

√  The high capacity rechargeable battery: Charging duration >3 hours, continuous working duration>8 hours.

√   Measuring Range:

     Leakage Current:0-10mA(extendable)

     Voltage:30-100V(extendable)

√  Measuring Precision:

     Current:Full current>100μA,±5% reading±1 digit

     Voltage:If reference voltage signal>30V, ±2% reading±1 digit

√  Measuring Parameters:

    1)      Full leakage current waveform / Fundamental harmonic effective value / Peak value.

    2)      The effective value of leakage current resistive component fundamental harmonic, and the effective value of 3 /5 /7 times.

    3)      The peak value of leakage current resistive component: positive peak Ir+, negative peak Ir-.

    4)      Capacitative current fundamental harmonic, phase angle difference of full voltage and current.

    5)      Voltage effective value.

    6)      Arrestor power consumptions.

√  Voltage reference signal sampling mode: 20m (extendable)

√  Overall size:: 360mm×260mm×140mm

√  Weight: 5.0kg

More information, please kindly contact with us, we can customize the suitable test set according your requirements and give you the best quotation. Thank you!
