GD6300 Large Capacity Capacitance and Dissipation Factor Tester

HV Hipot Electric Co., Ltd.
  • Function：Cleared
  • Display：LCD Screen
  • Usage：Electric Component Tester
  • Type：Capacitance Measuring Tester
  • Environment：-15-40degree
  • Warranty：With Warranty

Base Info

  • Model NO.：GD6300
  • Power Source：AC 85V-265V
  • Weight：55kg
  • Installation：Portable Precise
  • Customized：Non-Customized
  • Use Condition：-15--40 Degree
  • Humidity：Rh<80%
  • Anti-Interference Principle：Frequency Conversion
  • Power Supply：AC 220V±10%
  • Hv Output：0.5kv--18kv
  • Accurancy：2%
  • Max. Current：500mA
  • Capacity：5000va
  • Dimension：600(L)×450(W)×700(H)
  • Transport Package：Wooden Case
  • Specification：ISO, SGS
  • Trademark：HV Hipot
  • Origin：Wuhan China
  • HS Code：9031809090
  • Production Capacity：1000PCS,Year

Description

-15--40 degreeRH<80%2Anti-interference principleFrequency conversion3Power supplyAC 220V±10%Generator is permitted4HV output0.5KV--18KV0.1kV for stepAccuracy2%Max. current      500mACapacity5000VA5Resolutiontgδ: 0.001%Cx: 0.01pF6Accuracytgδ:±(1.0% of the reading+0.040%)C x :±(1.0% of the reading+1.00PF)7
Measurement rangetgδNo limitCx15pF < Cx < 1uF 18KVCx < 50  nF 10KVCx < 100 nF 5KVCx < 200 nF 1KVCx <  1  uF8Dimension600(L)×450(W)×700(H)9Storage200 group 10Weight55 kg
