• Model NO.：GD-4508G
• Dragging Speed：10~50mm,Min, Adjustable
• Delivery Time：10 Working Days
• Size：2365*530*1000mm
• PC Communication：Yes
• Transport Package：Wooden Case for Gd-4508g
• Trademark：GOLD
• Origin：Chongqing, China
• Production Capacity：100 Sets, Month

Product nameGd-4508g Bitumen Ductility Tester (Dual-Path) /Asphalt Ductility TesterPower supplyAC(220±10%)V,50HzMeasurement distance2mHeating power3200WTemperature controlRange:(5~35)ºC, accuracy: ±0.1ºCTensile speed(10~50)mm/min, stepless adjustment. accuracy:±1mmTensile testRange:(0~300)N, accuracy:±1N, resolution: 0.1NData output(1)Communication port RS232
(2)Printed by micro-printerRefrigerationCompressor 1.0P, input power is 800W
 Ambient temperature(-10~+35)ºC.Relative humidity≤85%Maximum power consumption4100WOverall dimension2365mm×530mm×1000mm



Related Products:

Parameter	GD-4508C	GD-4508G(Dual-path)
Auto./Manual	Semi-auto	Automatic
Measuring range	1.5m±10mm	2m
Temperature range	5~50 Celsius	5~50 Celsius
Temperature accuracy	±0.1Celsius	±0.1Celsius
Speed	10mm/min, 50mm/min	10~50mm/min, adjustable
Measuring accuracy	±1mm	±1mm
Force measurement	No	Yes
Refrigeration	Yes	Yes
PC communication	No	Yes
Data print	No	Yes
Size	2365*520*1000mm	2365*530*1000mm



Company  Information:

Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.

We mainly design and manufacture the petroleum testing instrument
After several years' development, our products have become high intelligent and wide coverage. And our company has become one of the leading manufacturer of petroleum testing instrument .
