• Model NO.：ZDM-1
• Control：Manual Control
• Weight：100-500Kg
• Power Source：AC380V
• Oil Cylinder Position：No
• Color：Blue
• Transport Package：Wooden Case
• Specification：1CBM
• Trademark：C-TECH
• Origin：China Mainland
• HS Code：90248000
• Production Capacity：500sets,Month

Basic Info.

Model NO. ZDM-1 Control Manual Control Weight 100-500Kg Power Source AC380V Oil Cylinder Position No Color Blue Transport Package Wooden Case Specification 1CBM Trademark C-TECH Origin China Mainland HS Code 90248000 Production Capacity 500sets/Month

Product Description

C-Tech vibration mills offer the full benefits of program controlled grinding processes for the preparation of samples for x ray fluorescence analysis. Control by programmable controller results in a substantial improvement in the reproducibility of sample preparation and consequently optimum analysis results.

Vibration grinding mills are suitable for the grinding of minerals, slags, ferro alloys, organic substances and other materials. The high speed of the drive motor enables even hard material to be ground with short process times. The robust design with twin eccentric disk bearings enable the grinding mills to achieve a long service life with a minimum of maintenance.

the grinding processes on the vibration mills are controlled reliably by a plc program. This eliminates incorrect handling or settings as sources of errors. The parameters can be accessed only through a password.

grinding vessels for a range of applications, with capacities of 10, 50 and 100 ml (steel and tungsten carbide) and 100 ml (agate) are available.

Manually operated clamping facility for the grinding vessels

Available type specifications:

Application	For very fast grinding of medium, hard and very hard material, sample grinding for "XRF" "XRD" and "AA".
Useful capacity	100ml (user to specify)
Maximum Feed size	5mm
Time required For grinding	1 to 3 minutes (depending on the material characteristics)
Output size	Upto 75 microns (depending on material properties).
Grinding elements	1 bowl+1 ring + 1 puck for 100 ml
Material of grinding element	Hardened steel with tough core / AISI304-SS / Lined tungsten carbide / Tungsten carbide lined with Ti Al N coating / Agate / Zirconia (Stabilised) / Toughened Alumina / Corundum (natural and sintered).
Timer	0-255 (minutes & seconds)
Power	AC380V10%, 50HZ, 3-phase+ Earth
Weight and Dimension	Machine: 180kg, 650x600x960mm Packed: 240kg, 820x760x1320mm(Ply wooden case) ZHM-3B Machine: 260kg, 710x810x1080mm Packed: 340kg, 780x880x1150mm(Ply wooden case)

























































Type	ZHM-1A
Feature	Single-vessel, Single-speed
Charging granularity	≤5 mm
Discharging granularity	≤75μm
Vessel cubage	100 cm3
Fill sample	20-70 gram
Vessel material	Tungsten carbide, Chrome-steel, Manganese-steel
Power supply	AC380V±10%/50Hz/3-phase+earth
Rotate speed ( r/min)	1400
Rated power (KW)	1.5
Dimension (mm)	650×600×960
Net weight (kg)	180
Ambient temperature	5-40 degrees
