Mechanical Parts Torsion Testing Machine
Dongguan Hongjin Test Instrument Co., Ltd.- After-sales Service：Lifetime Maintenance
- Warranty：1 Year
- Type：Torque Testing Machine
- Accuracy Grade：0.5
- Load Way：Electronic Load
- Loading Method：Static Load
Base Info
- Model NO.：HJ-66
- Display：Digital
- Weight：0-100Kg
- Power Source：AC220V
- Transport Package：Fumigation-Free Standard Export Wooden Box
- Trademark：Hongjin
- Origin：China
- Production Capacity：1000 Sets, Month
Description
ParameterMaximum torque 20Nm, 50Nm, 100Nm, 200Nm, 300Nm, 500Nm, 1000Nm, 2000Nm, 5000Nm,
10000Nm (the above are conventional equipment and can be customized) Testing machine level Level 0.5/Level 1 Angular resolution 0.01° Torsion speed control range 0.1°-720°/min can be customized Corner measurement range 0°-±99999° Indication repeatability relative error <0.5% Loading method Fully automatic Equipment weight About 300KG Completeness Meet the standards Power supply 220V, 50Hz Applicable Products Metal test pieces, mechanical test pieces, hardware test pieces, etc. Torque measurement range 1%-100% of full scale Test plus torque direction Two-way loading Torque Resolution 1/±300000 Test stroke 300-1000mm can be customized Relative error of torque indication <±0.5%/<±1% Relative error of torsion angle indication <±0.5% Torsion attachment Both sides discuss Exterior Should meet the requirements of GB/T2611 Protective function The testing machine has overload protection function
Features
The loading of the testing machine is controlled by the computer and the AC servo motor control system. The active chuck is driven to rotate and load by the AC servo motor and the cycloidal pinwheel reducer. The torque and torsion angle are detected by high-precision torque sensors and photoelectric encoders. The computer dynamically displays The relationship curve between the test angle and torque, the acceleration rate, the test peak value, etc. This testing machine is mainly used for torsion testing of metal and non-metallic materials, automobile-related parts, etc. It is a necessary device for measuring torsional performance in aerospace, transportation, building materials industry, scientific research departments, various engineering colleges and universities, and mechanics laboratories of industrial and mining enterprises.
The Introduction Of Hongjin
Hongjin products are widely used in paper products, packaging, ink printing, tape, luggage, footwear, leather products, environment, toys, baby products, hardware, electronic products, plastic products, rubber products and other industries, suitable for all scientific research units, Quality inspection agencies and academic fields. Products comply with UL, ASTM, JIS, GB, SO, TAPPI, EN, DIN, BS and other domestic and foreign standards. We have CE certificates, ISO certificates, and are a high-tech enterprise with more than ten years of experience.
Hongjin's services:
If you encounter any problems during future testing, we promise we will reply you within 48 hours and provide a solution within 3 working days. We can provide operation video and English operation manual. We can provide video conferencing.
1. Pre-sales service
--24-hour online service for your consultation.
-- Help with choosing the right model, and a range of services, people, advice.
--Provide laboratory planning and pre-sales technical guidance.
2. Intermediate service
-- give you the best offer
--Provide discounts on multiple sets of orders
-- Do the customer's request:
--Choose a payment term that is convenient for you.
--Prompt production and delivery, keep you informed.
-- Invoice value can be provided according to your needs to reduce tax.
3. After-sale service
--1 year warranty service and lifetime maintenance.
--Technical engineers can provide 24-hour after-sales guidance.
--Replacement of some parts
--Remote control technical consultation
--Machine lifetime maintenance service
4. Commitment:
We will sign a letter of commitment at the same time as signing the contract, which will increase your confidence in us.
5. Good packaging:
Simulation animation customers cover with bubble film before putting them into wooden boxes, which not only has good shock absorption, impact resistance, heat sealing, but also has the advantages of non-toxic, odorless, moisture-proof and corrosion-proof, and good transparency.
