Building Material Cone Calorimeter ISO 5660
Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.- Type：Building Material Cone Calorimeter
- Maxcapacity：<1000KN
- Accuracy Grade：0.5
- Load Way：Electronic Load
- Loading Method：Static Load
- Display：Digital
Base Info
- Model NO.：GD-5660
- Control：Computer Control
- Weight：100-500Kg
- Power Source：AC220V
- Oil Cylinder Position：Building Material Cone Calorimeter
- Item Name：Building Material Cone Calorimeter ISO 5660
- Reference Standards：ISO 5660, ASTM E1354, BS 476-15
- Measured Parameters 1：Heat Emission, Ignition Time, O2 Consumption
- Measured Parameters 2：Co and CO2 Generation, Flow of Ignited Gases
- Features 1：Large LCD Display, Small Size
- Features 2：Important Parts Are Imported From UK
- Cone Calorimeter Type：New
- Size：1750(W) * 600(D) * 2800(H)
- Net Weight：450kg
- Warranty Period：1 Year
- Transport Package：Packed in Container
- Specification：Refer to detailed description
- Trademark：GOLD
- Origin：Chongqing, China
- HS Code：9031809090
- Production Capacity：10 Sets,Month
Description
Test Results Parameters Unit Heat Flux kW/m2 Exhaust duct flow rate L/s C factor L/kgmK Ignition time and extinguisment time s Total oxygen consumption g Total Smoke Release m/m2 Mass loss and Mass loss rate g, g/s Heat release rate MJ/kg, kw/m2 Effective heat of combustion MJ/kg Carbon monoxide yield kg/kg Carbon dioxide yield kg/kg
Features:
Features:
- Integrated body and 19 analysis rack
- 17inch touch screen panel type PC for the whole control and automatic testing
- Automatic Spark Igniter to facilitate measurement of ignition time
- Auto Split Shutter automatically opened to transmit radiation to the sample
- Absorber-type glass protection door to facilitate sample observation during test and opening and closing
- UK Servomexs Gas Analyzer to exactly measure O2, CO, and CO2 concentrations up to 0.02%
- Port, heated filter, and heated line to measure toxic gases
- MFC(Mass Flow Controller) used for all gas flows, improving the accuracy of and automatically controlling the flux
- Portable water cooling system without the need for waterworks and plumbing when using the Heat Fluxmeter (for ISO 5660)
- UK RS Load Cell with improved accuracy to measure mass loss rate CC 2006 DAQ(Data Acquisition) Program controllable with the touch screen panel
