Degassing Test Chamber Vacuum Nitrogen Drying Oven Machine for Industrial Quality Control

Guangdong Yuanyao Test Equipment Co., Ltd.
  • Vacuum Temperature Range：a.P.~-98kpa
  • Temp. Fluctuation：+,_ 0.5c
  • Control Accuracy：0.1c
  • Interior Chamber Material：SUS#304 Stainless Steel
  • Heating System：Stainless Steel High-Speed Heater
  • Testing Temperature Range：Rt~250c

Base Info

  • Model NO.：YPOV-270
  • Transport Package：Good Package
  • Specification：CE, ISO, TUV, SGS Certificate
  • Trademark：Yuanyao
  • Origin：China
  • HS Code：90318090
  • Production Capacity：5 Sets,Month

Description

ModelYPOV-072YPOV-270YPOV-480YPOV-600YPOV-720Inner chamber size
W×H×D(cm)45×40×4060×90×5080×100×60100×100×60120×100×60Exterior chamber size
 W×H×D(cm)81×87×10896×137×118106×170×125126×170×125146×170×125Temperature range                      RT ~250ºC (400ºC)vacuum degree                      Atmospheric pressure ~ -98KpaPerformanceTemp.fluctuation                      ±0.5ºCTemp.uniformity                      ±5ºCControl accuracy                      0.1ºCHeating-up time                      RT~400ºC<120min,RT~250ºC<90minMaterialExterior chamber materialCold rolled plate + Powder coatingInterior chamber materialSUS#304 Stainless steel Insulation materialPU & fibergalss SystemAir circulation systemCooling fanVacuum systemEquipped with vacuum pumpHeating systemSUS#304 Stainless steel high-speed heaterControlling systemPID ControllerPower supply380V 60/50HZCustomization serviceNon-standard or special requirements are all welcom
