40kv Vlf Test Set for 6kv-10kv XLPE /6kv-10kv PVC Cables of Acceptance Tests at The Jobsite

Sansion Power Electric Co., Ltd.
  • Usage：Power Cable
  • Power：Electricity
  • Certification：CE
  • Customized：Customized
  • Color：Black
  • Test Voltage Range：30kv,40kv,50kv,60kv,70kv,80kv,90kv

Base Info

  • Model NO.：SXVLF
  • Output Frequency：0.1Hz,0.05Hz,0.02Hz
  • Model：Sxvlf
  • Accuracy：3%
  • Transport Package：Plywood Case
  • Specification：ISO9001 SGS
  • Trademark：Sansion
  • Origin：Wuhan, China
  • HS Code：9030339000
  • Production Capacity：100 Units

Description

ModelOutput Voltage/Current
(Peak)Load CapacityFuseControl UnitBoosterNet Dim.
(cm)Net Wt
(kg)Net Dim.
(cm)Net Wt
(kg)SXVLF-30/1.130KV/29mA0.1Hz ≤ 1.1uF8A28×37×22433×18×34250.05Hz ≤ 2.2uF0.02Hz ≤ 5.5uFSXVLF-40/1.140KV/29mA0.1Hz ≤ 1.1uF
8A
 28×37×22435×20×36450.05Hz ≤ 2.2uF0.02Hz ≤ 5.5uFSXVLF-50/1.150KV/59mA0.1Hz ≤ 1.1uF
10A
 28×37×22437×24×39450.05Hz ≤ 2.2uF0.02Hz ≤ 5.5uFSXVLF-60/0.560KV/59mA0.1Hz ≤ 0.5uF
20A
 28×37×22433×18×34
33×18×3425+450.05Hz ≤ 1.0uF0.02Hz ≤ 2.5uFSXVLF-70/0.570KV/59mA0.1 Hz, ≤0.5µF
20A
 28×37×22433×18×34
35×20×3625+450.05Hz, ≤1.0µF0.02Hz, ≤2.5µFSXVLF-80/0.580KV/59mA0.1 Hz, ≤0.5µF20A28×37×22433×18×34
37×24×3925+450.05Hz, ≤1.0µF0.02Hz, ≤2.5µFSXVLF-90/0.590KV/59mA0.1 Hz, ≤0.5µF
20A
 28×37×22433×20×35
37×24×3930+450.05Hz, ≤1.0µF0.02Hz, ≤2.5µF

√   Accuracy: 3%

√   Voltage +/- peak value error: ≤3%

√   Voltage waveform distortion: ≤5%

√   Working temperature: -10ºC+40ºC
√   Working humidity: ≤85%RH
