• Model NO.：HTPV-01
• Machine Standard：IEC 61215
• Delivery：30 Work Days
• Package：Stronger Wooden Case
• Transport Package：Stronger Wooden Case
• Specification：IEC 61215
• Trademark：HOTOTECH
• Origin：Dongguan
• HS Code：9031809090
• Production Capacity：50 Sets Per Month

Basic Info.

Model NO. HTPV-01 Machine Standard IEC 61215 Delivery 30 Work Days Package Stronger Wooden Case Transport Package Stronger Wooden Case Specification IEC 61215 Trademark HOTOTECH Origin Dongguan HS Code 9031809090 Production Capacity 50 Sets Per Month

Product Description

PV module Robustness Terminations Testing machine
Purpose

Measuring the the adhesion of terminals and the modules whether withstand normal force under installation and operation or not

Apparatus Comprise

1. Consist of Rack, handpiece, control box

2. Rack made of aluminum alloy assembled into a test platform, and use the middle of the chute and right angle connectors from aluminium alloy extrusions, fixed the modules on the platform conveniently, also installed the headpiece and control box in the rack

3. Headpiece: For installing motor, reducer, limit switch

4. Control box: Equipped control switch, digital delay meter, digital meter count

5. Control system

Brief description

1. Complete the specified distortion times automatically

2. Digital display the times of distortion

3. Set Pause time at 0° , 90° , 180° Arbitrary
Technical Parameters: Torsion test: One end of the conduit designed for manual knob, so as junction box and conduit installations revolution around the central axis within 1 minute according to the standard


Company introduction
  Dongguan Hong Tu Instrument Co.,Ltd specializes in developing and producing PV module testing machines and established in 2006 year , we have firm connections and full cooperation from China's National Third-party Quality Inspection and Notarization Center on producing and developing high-precision testing machines

  We treasue the value of good quality , reasonable price and efficient serivce with customer satisfaction. we expert ourselves in providing our customers the best suitable testing designs and high quality testing machines to make you the utmost profit







Rack dimension	2100mm*1600mm*760mm
Speed of head	10 s per semi-cycle
Installation about Module	Chuck fastening, be capable of a maximum area 2000mm*1500mm
Wire tension	Reached 0.5-4kg through hanging heavy mound
