High Precision Low Ripple Loop Resistance Tester (GDH-100)

HV Hipot Electric Co., Ltd.

Function：Cleared
Display：Digital
Usage：Electric Component Tester
Type：Resistance Tester
Environment：Room Temperature
Warranty：With Warranty

Base Info

Model NO.：GDH-100
Power Source：AC 85V-265V
Weight：0-10Kg
Installation：Direct Connected
Customized：Customized
Testing Current：DC 0-100A.
Accuracy：0.5%
Power Supply：AC 220V+-20%, 50Hz+-1
Dimension：36*27*30cm
Transport Package：Wooden Case
Specification：ISO, SGS
Trademark：HV Hipot
Origin：Wuhan China
HS Code：9030899090
Production Capacity：2000PCS,Year

Description

Input voltageAC220V±20%,50HzOutput currentDC 8~109A continuous adjustmentTest currentDC 100AAccuracy0.5%±1digitResolution1μΩMeasure range0-1999μΩDisplay3 ¹/₂ digitWith over-current, short circuit and overheat protection.
High Precision Low Ripple Loop Resistance Tester (GDH-100)

High Precision Low Ripple Loop Resistance Tester (GDH-100)
