Fully Automatic Flash & Fire Point Tester ASTM D92 Cleveland Open Cup
Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.- Power Supply:AC 220V, 50Hz
- Flash Point Determination:Ambient to 400celsius
- Temperature Accuracy:0.1celsius
- Heating Rate:(5-6)C, Min After Reaching The Preset Flash Point
- Igniting Mode:Electric Ignition
- Data Transmission Mode:Bluetooth
Base Info
- Model NO.:GD-3536D
- Diameter of Igniter:0.7mm~0.8mm
- Transport Package:Wooden Case for Flash & Fire Point Tester
- Specification:510mm× 320mm× 330mm
- Trademark:GOLD
- Origin:Chongqing, China
- Production Capacity:100 Sets, Month
Description
Fully Automatic Flash & Fire Point Tester ASTM D92 Cleveland Open Cup
Summary
This flash and fire point tester is designed and made as perGB/T3536-2008 Petroleum Products - Determination of Flash and Fire Points - Cleveland open cup methodand ASTM D 92 Standard Test Method for Flash and Fire Points by Cleveland Open Cup Tester. It is applicable to all petroleum products with flash points above 79ºC and below 400ºC except fuel oils.
I. Main technical features
1. It adopts an 8-inch IPS high-definition capacitive screen. Using 32-bit ARM processor and high-precision AD chip, the test data and parameters are recorded in real time and displayed by curve.
2. Automatic measurement of atmospheric pressure, automatic correction of flash point value.
3. Equipped with Bluetooth interface.The user can query test data anytime.
4. Electronic ignition, gas flame..
5. Remote automatic upgrade to obtain the latest version, remote prediction, abnormal early warning, comprehensive evaluation and maintenance of instrument operation status.
II. Main technical specifications
1. Power supply: AC(220±5%)V, 50Hz
2.Total power consumption:<=700W
3. Flash point determination: Range:Ambient to 400ºC;Accuracy:0.1ºC
4. Heating rate: (1)Initial heating:(14~17)ºC/min
(2)It is (5-6)ºC/ min after reaching the preset flash point 20ºC
5. Igniting mode:(1)Electric ignition,
(2)Diameter of igniter:0.7mm~0.8mm
6. Fire extinguishing device: (1) when the fire point appears, it can automatically extinguish the fire and return to its original position; (2) it can also manually press the key to extinguish the fire.
7. Data transmission mode:Bluetooth
8. Ambient temperature:(15~35)ºC
Relative humidity:≤85%
9.Dimension:510mm×320mm×330mm
10.Net weight:20kg
III. Exhabition:
Every year we participate in the various countries of the exhibition, will recommend our products to the needs of customers around the world.We have developed sales channels in many countries such as UAE, Saudi Arabia, Malaysia, Thailand, Pakistan, India, Germany, Belgium, USA, Mexico, Kenya, Nigeria, South Africa and other countries worldwide.
And we have gained strong advantage and high reputation in international market.

IV. Certificate:

About us:
Chongqing Gold Mechanical & Electrical Equipment Co.,Ltd is a high-tech enterprise for researching, designing, developing and producing scientific and measuring instruments. With its continuous drawing of lessonas, unremitting innovation and borrowing of advanced technology from both at home and abroad, our company is now becoming a professional manufacture of oil tester,laboratory instrument,road building instrument.
