XHDY205Primary transformer pressure test device

Product description

The transformer is the most critical bridge connecting primary equipment and secondary equipment, and is the basis for monitoring, analysis and control of secondary equipment. In particular, the transformers of intelligent substation use photoelectric transformers. In order to investigate the phase polarity of the photoelectric transformers and the differential protection action of the main transformer, it is important to test the primary side of the substation.

The device mainly applies voltage from the primary circuit of the substation, and tests the voltage circuit of the whole station through different wiring methods. The method is applied in the substation debugging process, which greatly improves the efficiency of commissioning work and the success rate of commissioning.



Main features

1. Friendly UI design, it's easy to operate;

2. Small size and light weight, which is especially suitable for the on-site testing;

3. Large-capacity output, two-grade voltage design, makes the product has a strong adaptability;

4. The pointer indicator design is clear to understand;

5. The fool-like design only needs to turn on the power, no need to adjust;

6. Special high-voltage output wire, it's safe and reliable;



Main Technical Parameters

1. Output voltage: 6.6kV, 11kV

2. Output accuracy: 2.5 level

3. Output power: 2000W

4. Working voltage: AC 220V±10%, 50Hz±5Hz

5. Output line: 10m withstand voltage 15kV

6. Insurance Tube: 6A

7.Size: 415×315×390 mm

8. Weight: 32.5kg
