• Model NO.：A1LXZ1
• Mass Scope of Workpiece：160kg
• Type：Balancing Machine
• Accuracy Grade：0.5
• Load Way：Electronic Load
• Loading Method：Static Load
• Display：Digital
• Control：Computer Control
• Weight：500-1000Kg
• Power Source：AC380V
• Oil Cylinder Position：Top
• Transport Package：Standard Export Wooden Box
• Specification：ISO. CE. SGS CNAS
• Trademark：JP
• Origin：Shanghai China
• HS Code：903110009
• Production Capacity：100 Sets,Month
• Package size per unit product：1300.00cm * 2100.00cm * 1630.00cm
• Gross weight per unit product：1058.000kg

Sr.no.

Specification

Parameter

1

Max. Weight of Workpiece (kg)

5kg

2

Max. Diameter of Workpiece(A)

200mm

3

Balancing Speed

≤1200r/min

4

Balancing Motor Power

2kW(servo motor)

5

Min. Achievable Residual Unbalance

≤1g.mm/kg

6

Measuring time

12-15S

7

Unbalance Reduction Ratio

≥90%

8

Operating Air Pressure

0.4~0.6MPa

9

Operating Voltage

AC:380V external connection

10

Milling Motor Power

3kW

11

Machine Total Power

9kW

12

Protection

Phase sequence protection, overload protection, air pressure monitoring
