Digital Bitumen Marshall Stability Tester

Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.
  • Marshall Stability：Marshal Stability Compressive Tester
  • Bitumen：Bitumen Digital Marshall Stability Tester
  • Asphalt：Asphalt Marshall Stability Tester
  • Stability Testing：Automatic Marshall Stability Testing Machine
  • Asphalt Mixture：Digital Marshall Stability Test Machine
  • Application：Asphalt Mixture Marshall Stability Test Apparatus

Base Info

  • Model NO.：GD-0709A
  • Transport Package：Wooden Case
  • Trademark：GOLD
  • Origin：Chongqing of China
  • HS Code：9031809090
  • Production Capacity：200PCS,Month

Description

Basic Info.

Model NO. GD-0709A Transport Package Wooden Case Trademark GOLD Origin Chongqing of China HS Code 9031809090 Production Capacity 200PCS/Month

Product Description

GD-0709A Digital Bitumen Marshall Stability Tester



Introduction:

This instrument is designed and made as per industrial standard T0709-2011 and ASTM D6927 in TG E20-2011 Specification and Test Methods of Bitumen and Bituminous Mixture for Highway Engineering. It is used to do the Marshall stability test for bituminous materials.



Features:

1. This instrument has functions of parameters setting, measurement calibration, automatic test control, automatic data collection and timer. The control unit will collect the stability and flow value for sample and judge the peak value automatically.

2. LCD display shows the stability, flow value, curves, result and time. The test effect is intuitive .

3. 100 groups of test data and test time can be stored in the instrument and callout whenever needed. All procedures will be controlled automatically.

4. RS232 communication port. Realize the communication with upper computer. The data process, store, print and display can be controlled by a PC. Also the test procedures can be controlled by a PC.

5. This instrument also has functions for manual lifting, lowering and stopping. Convenient to use.

Note:Ф100mm sample clamp is in standard accessory list for this instrument. Users can also select clamps as blow:

1. Sample clamp:   Ф150mm, one piece

2. Sample clamp:   Ф100mm and Ф150mm, one for each.


Specifications:

1. Maximum load:    50kN

2. Measuring range:   ≤40kN

3. Measuring bias:    ≤±0.1kN

4. Overload protection:    Automatically protect when load is over 39kN

5. vertical deformation(flow value):  Range 0~20mm, bias ≤±0.05mm

6. Lifting rate for pressure machine:  (50±5)mm/min

7. Communication port:  RS232

8. Power supply:   AC220V±10%,50Hz

9. Ambient temperature:   0ºC~60ºC

10.Dimension:     600mm×380mm×840mm

11.Motor power:    550W

12.Net weight:    98kg


Optional Accessories:

1. GDY-1 Low temperature thermostatic water bath

2. GD-0702 Marshall electric compactor
