BS Method Aggregate Crushing Value Apparatus
Zhuozhou Tianpeng Imp. & Exp. Trade Co., Ltd.- Material：Special Alloy Steel
- Transport Package：Standard Export Packages
- Trademark：C-TECH
- Origin：China Mainland
Base Info
- Model NO.：AC-150,AC-75
- HS Code：90248000
- Production Capacity：100 Pieces,Month
Description
Basic Info.
Model NO. AC-150/AC-75 HS Code 90248000 Production Capacity 100 Pieces/MonthProduct Description
Aggregate Crushing Value ApparatusSTANDARD: BS 812-110, 111
The aggregate crushing value provides a relative measure of the resistance of an aggregate to crushing under a gradually applied compressive load. Two versions of this apparatus are available: 150 (standard) and 75
mm diameter; both sets comprises a cylinder, plunger, base plate, tamping rod, and measure. The cylinder, plunger and base plate are made from special alloy steel.
AC-150 Aggregate Crushing Value Apparatus comprising
150 mm nominal diameter steel cylinder, plunger and base plate. Weight: 16.6 kg
Metal Measure 115 mm diameter x 180 mm deep. Weight: 870 g
Tamping Rod 16 mm diameter x 600 mm long with rounded end.
AC-75 Aggregate Crushing Value Apparatus comprising
75 mm nominal diameter steel cylinder, plunger and base plate. Weight: 3.5 kg
Metal Measure 57 mm diameter x 90 mm deep.
Tamping Rod 8 mm diameter x 300 mm long with rounded end. Weight: 350 g
