Concrete Compression Testing Machine
Zhuozhou Tianpeng Imp. & Exp. Trade Co., Ltd.- Type：Test and Measurement Instruments
- Maxcapacity：2000kn
- Accuracy Grade：1
- Load Way：Mechanical Load
- Loading Method：Dynamic Load
- Display：Digital
Base Info
- Model NO.：SYE-2000
- Control：Manual Control
- Weight：500-1000Kg
- Power Source：AC220V
- Oil Cylinder Position：Under
- Transport Package：Export Standard Package: Wooden Case.
- Specification：2000KN
- Trademark：C-tech
- Origin：China
- HS Code：90248000
- Production Capacity：100sets,Month
Description
Basic Info.
Model NO. SYE-2000 Control Manual Control Weight 500-1000Kg Power Source AC220V Oil Cylinder Position Under Transport Package Export Standard Package: Wooden Case. Specification 2000KN Trademark C-tech Origin China HS Code 90248000 Production Capacity 100sets/MonthProduct Description
COMPRESSION TESTING MACHINEMain features
• Meet the requirements of EN 12390-4 ASTM C39, AASHTO T22
• Tests 200, 150 and 100 mm concrete cubes and cylinders up to 320 x 160 mm diameter
• Platen handling machines include BS 6073-1, EN 772-1 specifi cation rectangular platens.
• Supplied with Windows download software.
| Model | SYE-2000 |
| Features | Manual load, Protect cover |
| Max load capacity | 2000kN |
| Compression space | 320mm |
| Piston stroke(mm) | 50 |
| Size of compression plates(mm) | 250×250 |
| Dimension(load frame mm) | 900×400×1150 |
| Power(kW) | 1.0 |
| Weight(kg) | 750 |
