Volt-Ampere Characteristic CT PT Comprehensive Transformer CT PT Tester Analyzer
Xi'an Xu&Hui Electromechanical Technology Co., Ltd.- Warranty：1 Year
- Turns Ratio Difference：Accuracy: 0.05%
Base Info
- Model NO.：XHFA201D
- Transport Package：Wooden Box with Foam Inside
- Specification：465mm*385*mm*425mm
- Trademark：XZH TEST
- Origin：China Xi′an
- HS Code：9030841000
- Production Capacity：1000pieces,Year
- Package size per unit product：46.50cm * 38.50cm * 42.50cm
- Gross weight per unit product：22.000kg
Description
Overview
Working power supply Working power supply Device output 0~2500Vrms, 5Arms (20A peak)
Note: 0~5A is the true value, and more than 5A~20A is the calculated value; High current output 0~1000A; excitation accuracy: ≤0.5% (0.2%* reading +0.3%* range) Secondary winding resistance measurement Range: 0.1 ~ 300Ω;
Accuracy: ≤ 0.5% (0.2% * reading + 0.3% * range) Secondary actual load measurement Range: 5 ~ 1000VA;
Accuracy: ≤ 0.5% (0.2% * reading + 0.3% * range) ± 0.1VA Phase measurement (angular difference) Accuracy: ± 4 min;
Resolution: 0.1 min Turns ratio difference accuracy: 0.05% CT ratio measurement Range: ≤ 25000A / 5A (5000A / 1A)
Accuracy: ≤ 0.5%
PT ratio measurement
Range: ≤500KV;
Accuracy: ≤0.5%
Product Description
Detailed Photos
Product Features
Product Parameters
Note: 0~5A is the true value, and more than 5A~20A is the calculated value;
Accuracy: ≤ 0.5% (0.2% * reading + 0.3% * range)
Accuracy: ≤ 0.5% (0.2% * reading + 0.3% * range) ± 0.1VA
Resolution: 0.1 min
Accuracy: ≤ 0.5%
Accuracy: ≤0.5%
