• Model NO.：48-D5242
• Transport Package：Wooden Case
• Specification：1100 *470 * 1200mm
• Trademark：C-TECH
• Origin：China
• HS Code：90248000
• Production Capacity：100,Month

Basic Info.

Model NO. 48-D5242 Transport Package Wooden Case Specification 1100 *470 * 1200mm Trademark C-TECH Origin China HS Code 90248000 Production Capacity 100/Month

Product Description

Deval Abrasion Testing Machine
standard:
EN 1097-1, EN 13450, NF P18-576
This machine is used to determine the resistance to wear of aggregates. The machine consists of a steel frame suitable to house four 200 mm dia.x 154 mm length cylinders (EN 1097-1) or two 200 mm dia.x 400 mm length cylinders (EN 13450). The top machine is enclosed in a sound proof and safety cabinet conforming to CE requirement and stops automatically when the cover is open. The machine is equipped with an automatic counter, which can be preset to the required number of revolutions of the drum or the
total working time. The four standard cylinders 200 mm dia.x 154 mm length are included. The 400 mm long cylinders and steel spheres are not included and have to be ordered separately. See accessories.



Features:
• Complete with four Stainless steel cylinders 200 mm dia.x154 mm length
• Suitable for rolling two 200 mm dia.x400 mm long cylinders
• Revolutions setting counter included
• Enclosed in safety protection



Model 48-D5242
Dimension: 1100 x 470 x 1200mm
Weight: 170kgs
Power: AC 220V 50HZ, single phase, 750 W
