Impact Test Chamber High Low Temperature Impact
Guangdong Yuanyao Test Equipment Co., Ltd.- Type：Impact Testing Machine
- Display：Digital
- Control：Controller
- Power Source：AC220V; AC380V
- Oil Cylinder Position：N,a
- Internal Size(Mm)：400*500*400
Base Info
- Model NO.：YTST-080
- Temp.Range：-10 Degree~+150 Degree
- Temp.Constancy：+,-2 Degree
- Temp.Recover Time：3 to 5 Min
- Material：Stainless Steel
- Circulation：Sirocco Fan
- Insulation：PU&Fiberglass Wool
- Heating：Chrome Steel Strip Wire Heater
- Controller：Clcd-9800
- Warranty：12 Months
- Transport Package：Strong Wooden Cases
- Specification：CE, TUV, SGS Certificate
- Trademark：Yuan Yao
- Origin：Guangdong, China
- HS Code：9032100000
- Production Capacity：100 Sets,Month
Description
ModelYTST-050 YTST-080 Test Area Dim.(mm) W×H×D 360×400×350 400×500×400 External Dim.(mm) W×H×D 1520×1820×1420 1650×1920×1420 High Temp. Range +80°C ~+200°C Low Temp. Range -10°C ~-40°C; -10°C ~60°C; -10°C ~-70°C Test Temp. Range +60°C ~-150°C;
-10°C ~-40°C; -10°C ~55°C; -10°C ~-65°C Performance Temp. Constancy ±2°C Temp. Recover Time 3 ~ 5min Heat-up Time °C 150 150 min 30 40 Pull-down Time °C -40 -50 -65 -40 -50 -65 min 60 70 80 60 70 80 Material Exterior Stainless steel plate+Powder Coated Interior SUS#304 stainless steel plate Insulation PU & Fiberglass wool Systems Circulation siroco fan Heating Chrome steel strip wire heater Cooling Compressor+evaporator fins+air-cooling(or water-cooling)condenser Controller CLCD-9800 Other Components Control status indicator lights, experiment separation shelves(freely adjustable 2pcs) Safety Devices Overheating prevention circuit-breaker,compressor overload protection,control system overload prevention,breakdown idicator lihgt,high-low compressure protection swith. Power Source(K.W.) AC 3Ψ380V 60/50Hz 20 21 22 21 22 23
-10°C ~-40°C; -10°C ~55°C; -10°C ~-65°C
