• Model NO.：GDJF-2008
• Weight：15kg
• Power Source：AC220V
• Ambient Temperature：0-40degree
• Relative Humidity：below 80%
• Power Supply：220V 50Hz
• Earthing Requirements：Earthing Resistance <1ohm
• Capacitance Range to Be Tested：6PF-250UF
• Channel：1-4 channel optioal
• Dimension：450*450*190 mm
• Delivery time：35 days
• Transport Package：Wooden Case
• Specification：SGS, ISO
• Trademark：HVHIPOT
• Origin：Wuhan, China
• HS Code：9030849000
• Production Capacity：600PCS,Year

Basic Info.

Model NO. GDJF-2008 Weight 15kg Power Source AC220V Ambient Temperature 0-40degree Relative Humidity below 80% Power Supply 220V 50Hz Earthing Requirements Earthing Resistance <1ohm Capacitance Range to Be Tested 6PF-250UF Channel 1-4 channel optioal Dimension 450*450*190 mm Delivery time 35 days Transport Package Wooden Case Specification SGS, ISO Trademark HVHIPOT Origin Wuhan, China HS Code 9030849000 Production Capacity 600PCS/Year

Product Description

Portable Digital Partial Discharge Free Detector GDJF-2008




GDJF-2008 Partial Discharge Detector is measuring partial discharge for the products  suchas transformers,
mutual inductors, HV switches, zinc monoxide arresters and power cables. It also can make type tests and monitor insulation operation.This type has the advantages of high sensitivity, wide range of capacitance, being
wellequipped for input unit impedance detecting and more variants of frequency bands ( 9 in all). After proper setting, the discharge impulse amount can be read directly. The indicating and digital meters are shown simultaneously.
This detector is widely applied in power stations, manufacturers and institutions.

Use Condition

Ambient temperature: 0-40ºC±2ºC.
Relative humidity: ≤80%
Power supply: 220V±10%,50HZ.
No violent vibration and mechanical shock
The device should be placed in the environment with no dust and corrosive, good ventilation. It should not be interfered by strong electromagnetic
Earthing requirements: earthing resistance <1Ω

Capacitance range to be tested 6PF-250μF

Testing sensitivity (shown in Table.1)


Input unit No.	Tuning capacitance	Unit	Sensitivity(pC) (Unsymmetrical circuit)
1	6-25-100	pF	0.02
2	25-100-400	pF	0.04
3	100-400-1500	pF	0.06
4	400-1500-6000	pF	0.1
5	1500-6000-25000	pF	0.2
6	0.006-0.025-0.1	mF	0.3
7	0.025-0.1-0.4	mF	0.5
8	0.1-0.4-1.5	mF	1
9	0.4-1.5-6.0	mF	1.5
10	1.5-6.0-25	mF	2.5
11	6.0-25-60	mF	5
12	25-60-250	mF	10
7R	Resistance		0.5

Table 1

Amplifier band

Low terminal: 10KHZ, 20 KHZ, 40 KHZ (optional)
High terminal: 80 KHZ, 200 KHZ, 300 KHZ (optional)

Amplifier gain adjustment

Coarse control - there are 6 gears for coarse tuning, the gain of each gear is 20±1db
Fine control ≥ 20 db

Time windows

Width of window, adjustable 15o-150o
Window position, adjustable 0o-170o
Two windows can be opened simultaneously or separately.

Discharge meter

Digital display
PD display: LED 3½ digits
0-100.0    limit of error <±3% (full scale)

Ellipse time base

Frequency: 50Hz and arbitrary frequency
Elliptic display color is yellow
Elliptic rotation: each gear is 30°, 180 ° rotation can be made.
Display: ellipse - straight line
High frequency time base  elliptical input voltage less than 220 V, intake power < 1 VA

Waveform lock

Lock required waveform of any time to facilitate observation and analysis

Testing Voltage meter

Range: 100KV (Can be expanded)
Display 31/2 digital voltage meter
Accuracy: better than ±2% (full scale)

Inside, outside the zero mark function

Dimensions: 450×450×190 mm

Weight: about 16kg

Please well note that different channel number , price is different .
