GDZG-S-60kV/300mA Portable DC Hipot Tester for Water Cooled Generator

HV Hipot Electric Co., Ltd.
  • Type：hipot test
  • Maxcapacity：<1000KN
  • Accuracy Grade：1
  • Load Way：Electronic Load
  • Loading Method：Static Load
  • Display：Digital

Base Info

  • Model NO.：GDZG-S-60kV,300mA
  • Control：Microcomputer
  • Weight：100-500Kg
  • Power Source：AC220V
  • Voltage Measurement Error：1.0% 1digit
  • Current Measurement Error：1.0%
  • Overvoltage Setting Error：1.0%
  • Ripple Coefficient：3.0%
  • Voltage Stability：1.0%
  • Warranty：1 year
  • Transport Package：Wooden Case
  • Specification：ISO, SGS
  • Trademark：HV Hipot
  • Origin：Wuhan China
  • HS Code：9030339000
  • Production Capacity：20sets,Month

Description

50/15060/20060/30080/20080/300Output voltage(kV)505060608080Output current(mA)80150150300200300Output power(W)400075009000180001600024000Voltage measurement error≤ 1.0% ± 1digitCurrent measurement error≤ 1.0% ± 1digitOvervoltage setting error≤ 1.0%Ripple coefficient≤ 3.0%Voltage stability≤ 1.0%Power supplyAC220VAC380V(three phase, four wire)
