Product Description

Strain controlled triaxial test apparatus



Model TSZ10-1.0
Sample dimension: Ф39.1×80 mm
Max load: 10Kn
Strain rate: 0.016-1.6mm/min. six-speed mechanical transmission
Table stroke: Max. 50mm
Confining pressure: 0-1Mpa
Back pressure: 0-0.6Mpa
Hole pressure: 0-1Mpa
Volume change: 0-25ml
Graduation: 0.1ml
Axial displacement: 0-30mm
Power: 220V±10%, 50Hz
Machine dimension: 350 x 300 x 1100 (LxWxH)
Controller Dimension(mm): 500 x 500 x 925 (LxWxH)
Weight: 170 Kg

Model TSZ30-2.0
Sample dimension: Ф39.1×80 mm, Ф61.8×125 mm
Max load: 30Kn
Strain rate: 0.0024-4.5mm/min. sixteen-speed mechanical transmission
Table stroke: 0-90mm
Confining pressure: 0-1Mpa
Back pressure: 0-0.6Mpa
Hole pressure: 0-1Mpa
Volume change:0-25ml
Graduation: 0.1ml
Axial displacement: 0-30mm
Power: 220V±10%, 50Hz
Machine dimension: 350 x 300 x 1100 (LxWxH)
Controller Dimension(mm): 500 x 500 x 925 (LxWxH)
Weight: 175 Kg

Model TSZ-1, TSZ-1A, TSZ-2, TSZ-6
Sample dimension: TSZ-1,TSZ-1A:Ф39.1×80 mm,
                                TSZ-2:Ф39.1×80 mm, Ф61.8×125 mm
                                TSZ-6: Ф39.1×80 mm, Ф61.8×125 mm, Ф101×200 mm
Shearing rate: 0.0001-2.4mm/min. 0.0001-4.8mm/min
Confining pressure: 0-2Mpa
Back pressure: 0-2Mpa, TSZ-1A without back pressure
Hole pressure: 0-2.0Mpa
Volume change: TSZ-1, TSZ1A, TSZ-2: 0-50ml
Graduation: TSZ-6: 0-100ml
Axial displacement: 0-30mm
Axial load: TSZ-1, TSZ-1A: 0-10KN; TSZ-2: 0-30KN, TSZ-6: 0-60KN
