Portable Microcomputer 80kV Insulation Oil Dielectric Strength Tester for Transformer

HV Hipot Electric Co., Ltd.
  • Type：Test and Measurement Instruments
  • Maxcapacity：80kv
  • Accuracy Grade：1
  • Load Way：Electronic Load
  • Loading Method：Dynamic Load
  • Display：Digital

Base Info

  • Model NO.：GDOT-80
  • Control：Manual Control
  • Weight：0-100Kg
  • Power Source：AC220V
  • Power Supply：AC220V±10%, 50Hz
  • Output Voltage：80kv
  • Capacity：2.0 kVA
  • Speed of Voltage Increase：About 2 K V, S
  • Voltage Inspection Accuracy：1 %
  • Breakdown Sensitivity：< 0.1 Kv
  • Waveform Distortion：≤ 1 %
  • Transport Package：Wooden Case
  • Specification：ISO, SGS
  • Trademark：HV Hipot
  • Origin：Wuhan China
  • HS Code：9030899090
  • Production Capacity：2000PCS,Year

Description

Storage environmentTemperature: 0 ºC -40 ºCHumidity: Max. relative humidity 85%Storage environmentTemperature: - 20 ºC - 60 ºCHumidity: Max. relative humidity 75%Altitude<1500m (if over 1500m, it can be customized)Dimension420mm*400mm*380mm(100kV)Weight45kg(N.W.) (100kV)
