• Model NO.：GD-3536
• ASTM D92：Test Flash and Fire Points of Petroleum Products
• Operation：Manual Operation
• Heating Power：Continuously Adjustable
• Power Consumption：No More Than 650W
• Ignition Source：Coal Gas(or Civil Gas)
• Nozzle Aperture：About 0.8mm
• Net Weight：5.5kg
• Transport Package：Wooden Case
• Origin：Chongqing China
• HS Code：9031809090
• Production Capacity：200 PCS , Month

Basic Info.

Model NO. GD-3536 ASTM D92 Test Flash and Fire Points of Petroleum Products Operation Manual Operation Heating Power Continuously Adjustable Power Consumption No More Than 650W Ignition Source Coal Gas(or Civil Gas) Nozzle Aperture About 0.8mm Net Weight 5.5kg Transport Package Wooden Case Origin Chongqing China HS Code 9031809090 Production Capacity 200 PCS / Month

Product Description

Manual ASTM D92 Cleveland Flash & Fire Point Tester

Significance of Flash / Fire Point:

1. The flash point is one measure of the tendency of the test specimen to form a flammable mixture with air under controlled laboratory conditions.
2. Flash point is used in shipping and safety regulations to define flammable and combustible materials.
3. Flash point can indicate the possible presence of highly volatile and flammable materials in a relatively nonvolatile or nonflammable material.
4. The fire point is one measure of the tendency of the test specimen to support combustion.
5. The ASTM D92 Cleveland Flash & Fire Point Tester is used for the determination of the flash point and fire point of petroleum products.


Features:

1.The Cleveland open cup apparatus adopts special heating furnace to ensure the safety of test.
2.The heating power is continuously adjustable.It can meet requirements of test.
3.The Cleveland open cup apparatus is fully self-contained complete.The operator can do determination as long as connecting with coal gas or other civil gas.
4.With fast cooling function, it can improve test efficiency.


Specifications:

1.Power supply:    AC(220±10%)V, 50Hz.
2.Power consumption: <=650W
3.Heating device: furnace heating, no naked fire, explosion prevented.The power is adjustable from 0W to 600W.
4.Test flame applicator: It applies the test flame automatically.
5.Thermometer: (-6~400)ºC, Scale is 2ºC. It is the same as thermometer ASTM 11C.
6.Igniting device: (1) Ignition source: coal gas(or civil gas); (2) Nozzle aperture: about 0.8mm
7.Ambient temperature:  (15∼35)ºC , Relative humidity: ≤85%
8.Dimension: 350mm*290mm*350mm (thermometer is not included)
9.Net weight: 5.5kg.


Real Picture:
