3 Phase Transformer Turns Ratio Vector Group Test TTR Tester
Huazheng Electric Manufacturing (Baoding) Co., Ltd.- After-sales Service：Yes
- Warranty：1 Years
- Type：Vector Group Tester
- Maxcapacity：0.9-10000
- Accuracy Grade：0.1 Class
- Load Way：Electronic Load
Base Info
- Model NO.：HZBB-10S
- Loading Method：Dynamic Load
- Display：Digital
- Control：Manual Control
- Weight：0-100Kg
- Power Source：AC220V
- Oil Cylinder Position：No
- Test Range：0.8-20000
- Group：0-11
- Accuracy：0.1
- Phase Test Range：0 ~ 360 °
- Phase Measurement Accuracy：0.12 °
- Retardation Resolution：0.001 °
- Instrument Power Input：220V ± 22V, 50Hz ± 1Hz
- Dimensions：258 × 158 × 58 (mm)
- MOQ：1
- Certificate：ISO,Ec
- Transport Package：Box
- Specification：ISO,CE
- Trademark：HuaZheng
- Origin：Baoding, Hebei
- HS Code：9030820000
- Production Capacity：500set ,Year
Description
Accuracy
±(Reading×0.1%+2 words)(≤500)
±(Reading×0.2%+2 words)(>500≤3000)
±(Reading×0.3%+2 words)(>3000)
Resolution ration
0.9~9.9999(0.0001)
10~99.999(0.001)
100~999.99(0.01)
1000~9999.9(0.1)
10000 and above(1)
Working power supply
The built-in battery or external charger, charger conditions of use,Input 100-240 VAC,50/60 HZ
Charging time
About 2 hr
Instrument weight
1.7 kg
Instrument dimension
246 mm(L)×156 mm(W)×62 mm(H)
Use of temperature
-10ºC~50ºC
Relative humidity
≤90%,No dew
