• Model NO.：GDHL-100H
• Weight：0-100Kg
• Power Source：AC220V
• delivery time：7 working days
• output current：30,50,80,100A
• Transport Package：Standard Export Bag
• Specification：ISO, SGS
• Trademark：HV Hipot
• Origin：Hubei, China
• HS Code：9030899090
• Production Capacity：50000sets,Year

Basic Info.

Model NO. GDHL-100H Weight 0-100Kg Power Source AC220V delivery time 7 working days output current 30/50/80/100A Transport Package Standard Export Bag Specification ISO, SGS Trademark HV Hipot Origin Hubei, China HS Code 9030899090 Production Capacity 50000sets/Year

Product Description

Portable 100A Circuit Breaker Loop Resistance Tester GDHL-100H

General Information

The product is mainly used for the contact resistance of switch contacts and other micro-ohmic resistance measurement, and the test speed is fast and the accuracy is high. This handheld contact resistance tester is an innovative product that is compact, hand-held, battery powered and easy to carry.

Features


1. Lithium battery power supply, can be tested more than 600 times after a single charge, the test process is simple and convenient.
2. The output current is up to 100A, multiple currents are available, and the test range is wide.
3. The longest test time can reach 60 seconds at 100A , to meet various applications on site.
4. Wide range and high precision, up to 5mΩ at 100A.
5. It has perfect protection functions such as open circuit protection and overheat protection.
6. 5.6-inch large industrial-grade high-brightness color LCD screen, the display is still clearly visible under strong sunlight.
7. Optional external printer for easy data printing.
8. With local storage and USB storage for easy data storage.

Specifications


Test Current	30A, 50A, 80A, 100A
Measurement range	30A:  0~20mΩ 50A:  0~10mΩ 80A:  0~8mΩ 100A : 0~5mΩ
Accuracy	± (Reading *0.5%+1uΩ)
Resolution	0.1uΩ
Display digital	4 1/2 digital
Test power supply	Constant current limit, about 2V
Input voltage	Max. 5V
Test time	Quickly , 10s-60s optional
Battery capacity	7.5AH power lithium battery
Measurement time	More than 600 times (rechargeable, fast measurement mode)
Test Wire	Resistance less than 10mΩ
Power supply	100~240VAC,50Hz/60Hz , built-in Rechargeable Lithium battery  charge voltage: 12.6V Cahrge current: ≤3A charge time :  about 3 hours  , automatic shut off after 5 minutes no operation
Weight	1.7 kg
