Military Quality Compact Temperature and Humidity Controlled Chambers

Guangdong Komeg Industrial Co., Ltd.
  • After-sales Service：24 Hours on Line Services
  • Warranty：12 Months
  • Type：Material Testing Machine
  • Weight：100-500Kg
  • Power Source：AC380V
  • Temp. Range：-70oc~+150oc

Base Info

  • Model NO.：KMH-S series
  • Humidity Range：20-98%R.H.
  • Temp. Constancy：+,-0.5oc
  • Humidity Constancy：+,-2.5%R.H.
  • Humidity Uniformity：+,-3.0%R.H.
  • Heat up Time：-70oc~+100oc Within 60mins
  • Pull Down Time：+20 Oc~-70 Oc Within 80mins
  • Transport Package：Strong Plywood Case, Meet International Standards
  • Specification：Standard and Customized
  • Trademark：KOMEG
  • Origin：Dongguan, China
  • HS Code：90321000
  • Production Capacity：1000 Sets Per Yesr

Description

Technical parameters:Environmental Temperature and Humidity ChamberSecifications ( at +20°C  room temp.  Or+25°C  water temp with empty load)ModelKMH-S series225S408S800S1000SInterior sizelW(mm)70070010001000H(mm)70075010001000D(mm)4808008001000Exterior sizeW(mm)98098012801280H(mm)1890194021602160D(mm)1460174017501950Weight(KG)330450550650Temp. range -70 °C ~+150°C Humidity Range20 ~ 98&R.H.Temp. constancy±0.5ºC   Humidity constancy±2.5%R.HHumidity uniformity±3.0%R.H±5.0 % R.HHeat up time -70°C  ~ +100°C , within 60 minPull down time +20°C  ~ -70°C  , within 80 minEquipment Power9.5KW10.6KW18.5KW18.5KWAmbient Temp.5ºC  ~+35ºC  Standard accessoriesSight window*1,  cable port(port 50mm)*1, shelves*2, chamber lamp*1, power cable *2mSafety device  (standard)No fuse breaker, over pressure over heat and over current protection for compressor,Over temp. protect, over load protect of blower, dry heat protectionControl SystemBalanced Temperature & Humidity Control SystemRefrigeration systemAir Cooled (Water Cooled Type is option)Hermetic compressor,Cascsde Refrigeration       CFC-Free refrigerant(HFC-507/HFC-23)ControllerPanel:7-inch LCD Touch panel,    Chinese or English display selectableOperation model :Program or fix point runningMemory capacity :120programs,1200steps,All repeat 999 cycles, part repeat 99 cyclesInterior materialStainless Steel Plate ( SUS 304 )Exterior materialBaked Painting Steel Or Stainless steel(SUS304)Insulation materialRigid polyurethane Foam and Glass Fiber WoolSystemBalanced & Humidity Control SystemWiring methodAC 380±10 %  50Hz ,3 phase 4 wires +Ground WiresNote: 1. We reserve the right to change specifications without prior notice
2. Customized sizes and configurations available

Standard Met and Implemented:

GB/Bb T2423.2-89 high temperature test method

GB2423.1-89 test A: low temperature test method 6

GJB150.4-1986 test at low temperature

IEC60068-2-1 low temperature test method

IEC60068-2-38 temperature cycle

IEC60068-2-78 constant humidity temperature

MIL - STD - 202G - 103B humidity test

IEC60068-2-30 humidity temperature cycle

GB/T2423.3 constant humidity heat test method
The technical parameter:
Standard configuration
Sight window*1, cable port(portΦ 50mm)*1, shelves*2, chamber lamp*1, power cable *2m
No fuse breaker, over pressure, over heat and over current protection for compressor,
Over temperature protection, over load protect of blower, dry heat protection

Optional accessories
Cable Port: Φ 100mm cable port is available
Shelves
Ro-type water purifier: R-80/day
Provide to keep the humidifying heater and wet bulb wick free from scale.
Inner glass door with operation port
A glass door can be provided behind the main door so that specimens can be observed. Two operation ports of 130mm diameter are used for handing specimens inside the chamber without opening the glass door.

Dehumidifier
The rotation regenerating dehumidifier M-120 ensures precise control of low humidity (5º C 5%RH) for electrostatic reliability tests.
Temperature and humidity recorder
-100 to +150º C/0 to 100%RH 100mm with effective width 100mm and 2 pen
Temperature 1 pen and humidity 1 pen.
-100 to +150º C/0 to 100%RH 100mm with effective width 100mm and 6 dots
Temperature 3 dots and humidity 1 dot.
-100 to +150º C/0 to 100%RH 100mm with effective width 180mm and 12 dots
Temperature 6 dots and humidity 6 dots.
Defrosting circuit
The chamber automatically detects and melts the frost on the evaporator when operating below 0º C.
Liquid or infection
In order to rapidly decrease the temperature inside the chamber, a cylinder of liquid can be connected the chamber.


Besides Reliable Environmental Test Chambers Manufacturers, we also supply:
3-zone/ 2-zone Thermal Shock Chamber
Walk-in Constant Temp. And Humidity Chamber
Rapid Temp. Change Chamber
Precise Drying Test Chamber
Temperature/ humidity/ vibration three integrated Chamber
Precise Drying Chamber
Vacuum oven/ no oxidation oven
Air Exchange Type Aging Oven
Burn-in Room
Salt spray Chamber
Two wing Drop Tester
Vibration Testing Machine

What is environment test

Military Quality Compact Temperature and Humidity Controlled Chambers

Expose the products in the natural surroundings or in the simulation environment, then evaluate their performance under practical environment when during storage, transportation and usage. Environment test is a vital way for quality assurance, since it can provide info about design and products quality.

After-sale serviceMilitary Quality Compact Temperature and Humidity Controlled ChambersIf you face any problems in future during testing process we promise we will give you a reply within 48 hours and solution provide within 3 working days. We can offer operation video and English operation muanual. We can provide video-conference. If customers require on-site service, the transport and travel expense shall be borne by customer.
