Model | WDW-50 | WDW-100 |
Maximum test force | 50kN | 100kN |
Accuracy class | Class one |
Test force measurement range | 0.4% - 100% FS |
Relative error of test force indication value | within ±1% of the indicated value |
Test force resolution | 1/±300,000 of the maximum test force (the resolution of the whole process is constant) |
Deformation measurement range | 0.2%-100% FS |
Deformation indication relative error | within ±0.5% of the indicated value |
Deformation resolution | 1/±300,000 of the maximum deformation (the resolution of the whole process is unchanged) |
Large deformation measurement range (optional accessory) | 10-800mm |
Large deformation indication relative error | within ±0.5% of the indicated value |
Large deformation resolution | 0.008 mm |
Relative error of displacement indication | within ±0.5% of the indicated value |
Displacement resolution | 0.0025mm |
Force control rate adjustment range | 0.005-5% FS/S |
Force control rate relative error | within ±1% of the set value |
Deformation rate adjustment range | 0.02-5% FS/S |
Deformation control rate relative error | when the rate is < 0.05% FS, it is within ±2% of the set value; when the rate is ≥0.05% FS, it is within ±0.5% of the set value |
Beam speed adjustment range | 0.001-500mm/min |
Relative speed error of beam | when the rate is < 0.01mm/min, within ±1.0% of the set value; when the rate is ≥0.01mm/min, within ±0.2% of the set value |
Constant force, constant deformation, constant displacement control range | 0.5% - 100% FS |
Constant force, constant deformation, constant displacement control accuracy | when the set value <10%FS, it is within ±1% of the set value; when the set value ≥10%FS, it is within ±0.1% of the set value |
Effective stretching space | 600mm |
Effective test width | 550mm |
Main frame dimension | 1000 × 700 × 2100mm |
Power supply | 220V ± 10%, 1.5W |
Host weight | about 850kg |
