- Model NO.:KTS-D Series
- Refrigeration System:Water Cooled
- Power:AC 380;10%50Hz
- Controller:LCD Touch Panel
- Product Name:Thermal Shock Chamber
- Transport Package:Strong Plywood Case, Meet International Standard
- Specification:Standard and Customized
- Trademark:KOMEG
- Origin:Dongguan China
- HS Code:90321000
- Production Capacity:1000 Sets,Year
3 Zone Thermal Shock Test Chamber |
Specifications | Note:1. We reserve the right to change specifications without prior notice 2. Customized sizes and configurations available |
Model | KTS-A Series |
72A | 100A | 150A | 200A | 252A | 300A | 480A |
Interior size | W(mm) | 450 | 500 | 600 | 670 | 700 | 800 | 800 |
H(mm) | 400 | 450 | 500 | 600 | 600 | 600 | 800 |
D(mm) | 400 | 450 | 500 | 500 | 600 | 650 | 750 |
Exterior size | W(mm) | 1490 | 1540 | 1640 | 1720 | 1750 | 1850 | 1850 |
H(mm) | 1790 | 1840 | 1890 | 2000 | 2000 | 2000 | 2200 |
D(mm) | 1600 | 1700 | 1830 | 1850 | 1930 | 1980 | 2500 |
Test weight(KG) | 5 | 10 | 12 | 15 | 18 | 20 | 20 |
Low Temp. chamber | -55ºC~-10ºC |
Pre-heat time | +20ºC~-55ºC ,Within 60 min |
Test. chamber | -40ºC~+150ºC |
High Temp. chamber | +60ºC~+200ºC |
Pre-heat time | +60ºC~+200ºC ,Within 20 min |
Recovery time | High-Temp Exposure 30 min |
Low-Temp Exposure 30 min |
Recovery time within 5 min |
Safety device | No fuse breaker, over pressure\over heat and over current protection for compressor,over temperature protection, over load protection for blower, dry heat protection |
Standard accessory | Cable port(portΦ50mm)*1, shelves*2 |
Interior material | Stainless steel plate(SUS 304) |
Exterior material | Baked painting steel or stainless steel(SUS304) |
Insulation material | Rigid polyurethane Foam+glass fiber wool |
Refrigeration system | Water Cooled |
Semi-hermetic compressor, cascade refrigeration system, CFC free refrigerant(HFC-507 and HFC-23) |
Controller | Panel:7-inch LCD Touch panel,Chinese or English display selectable |
Operation model:Program or fix point running |
Memory capacity:120programs,1200steps,all repeat 999cycles,part repeat 99 cycles. |
Accuracy:Temp.:0.1% of F.S±1 digit Humidity:0.1% of F.S±1 digit |
Input:Temp.:pt-100 Humidity:pt-100 or ~5V DCV |
Ambient Temp. | +5ºC~+35ºC |
Power | AC 380±10%50Hz ,3 phase 4 wires +Ground Wires |
3 Zone Thermal Shock Test Chamber |
Specifications | Note:1. We reserve the right to change specifications without prior notice 2. Customized sizes and configurations available |
Model | KTS-B Series |
72B | 100B | 150B | 200B | 252B | 300B | 480B |
Interior size | W(mm) | 450 | 500 | 600 | 670 | 700 | 800 | 800 |
H(mm) | 400 | 450 | 500 | 600 | 600 | 600 | 800 |
D(mm) | 400 | 450 | 500 | 500 | 600 | 650 | 750 |
Exterior size | W(mm) | 1490 | 1540 | 1640 | 1720 | 1750 | 1850 | 1850 |
H(mm) | 1790 | 1840 | 1890 | 2000 | 2000 | 2000 | 2200 |
D(mm) | 1600 | 1700 | 1830 | 1850 | 1930 | 1980 | 2500 |
Test weight(KG) | 5 | 10 | 12 | 15 | 18 | 20 | 20 |
Low Temp. chamber | -70ºC~-10ºC |
Pre-heat time | +20ºC~-70ºC ,Within 60 min |
Test. chamber | -55ºC~+150ºC |
High Temp. chamber | +60ºC~+200ºC |
Pre-heat time | +60ºC~+200ºC ,Within 20 min |
Recovery time | High-Temp Exposure 30 min |
Low-Temp Exposure 30 min |
Recovery time within 5 min |
Safety device | No fuse breaker, over pressure\over heat and over current protection for compressor,over temperature protection, over load protection for blower, dry heat protection |
Standard accessory | Cable port(portΦ50mm)*1, shelves*2 |
Interior material | Stainless steel plate(SUS 304) |
Exterior material | Baked painting steel or stainless steel(SUS304) |
Insulation material | Rigid polyurethane Foam+glass fiber wool |
Refrigeration system | Water Cooled |
Semi-hermetic compressor, cascade refrigeration system, CFC free refrigerant(HFC-507 and HFC-23) |
Controller | Panel:7-inch LCD Touch panel,Chinese or English display selectable |
Operation model:Program or fix point running |
Memory capacity:120programs,1200steps,all repeat 999cycles,part repeat 99 cycles. |
Accuracy:Temp.:0.1% of F.S±1 digit Humidity:0.1% of F.S±1 digit |
Input:Temp.:pt-100 Humidity:pt-100 or ~5V DCV |
Ambient Temp. | +5ºC~+35ºC |
Power | AC 380±10%50Hz ,3 phase 4 wires +Ground Wires |
3 Zone Thermal Shock Test Chamber |
Specifications | Note:1. We reserve the right to change specifications without prior notice 2. Customized sizes and configurations available |
Model | KTS-D Series |
72D | 100D | 150D | 200D | 252D | 300D |
Interior size | W(mm) | 450 | 500 | 600 | 670 | 700 | 800 |
H(mm) | 400 | 450 | 500 | 600 | 600 | 600 |
D(mm) | 400 | 450 | 500 | 500 | 600 | 650 |
Exterior size | W(mm) | 1490 | 1540 | 1640 | 1720 | 1750 | 1850 |
H(mm) | 1790 | 1840 | 1890 | 2000 | 2000 | 2000 |
D(mm) | 1600 | 1700 | 1830 | 1850 | 1930 | 1980 |
Test weight(KG) | 5 | 10 | 12 | 15 | 18 | 20 |
Low Temp. chamber | -80ºC~-10ºC |
Pre-heat time | +20ºC~-80ºC ,Within 60 mins |
Test. chamber | -65ºC~+150ºC |
High Temp. chamber | +60ºC~+200ºC |
Pre-heat time | +60ºC~+200ºC ,Within 20 min |
Recovery time | High-Temp Exposure 30 min |
Low-Temp Exposure 30 min |
Recovery time within 5 min |
Safety device | No fuse breaker, over pressure\over heat and over current protection for compressor,over temperature protection, over load protection for blower, dry heat protection |
Standard accessory | Cable port(portΦ50mm)*1, shelves*2 |
Interior material | Stainless steel plate(SUS 304) |
Exterior material | Baked painting steel or stainless steel(SUS304) |
Insulation material | Rigid polyurethane Foam+glass fiber wool |
Refrigeration system | Water Cooled |
Semi-hermetic compressor, cascade refrigeration system, CFC free refrigerant(HFC-507 and HFC-23) |
Controller | Panel:7-inch LCD Touch panel,Chinese or English display selectable |
Operation model:Program or fix point running |
Memory capacity:120programs,1200steps,all repeat 999cycles,part repeat 99 cycles. |
Accuracy:Temp.:0.1% of F.S±1 digit Humidity:0.1% of F.S±1 digit |
Input:Temp.:pt-100 Humidity:pt-100 or ~5V DCV |
Ambient Temp. | +5ºC~+35ºC |
Power | AC 380±10%50Hz ,3 phase 4 wires +Ground Wires |
Main features of Thermal test chamber:
1. Programmable Controller with RS232C, 7 LCD touch panel control
2. Stainess steel Interior, galvanized steel sheet exterior
3.2PCS stainless steel loading shelves free
4. Multipane viewing window with heater
5. 50mm diameter feed-through port
6. Floor stand with castors.
Packaging:
Climatic thermal shock test chamber are covered with air bubble film before put them into the strong plywoodcase, which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture corrosion, crash-proof, etc.
