Lubricating Oils Foaming Characteristics Analyzer for Determing The Foaming Tendency
Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.- Power Source：AC220V
- Product Name：Lubricating Oils Foaming Characteristics Analyzer
- Standard：ASTM D892
- Air Flow Rate：94 Ml,Min, Adjustable
- Structure：Low Temperature Bath+High Temperature Bath+Cooler
- Temperature Control Accuracy：0.5 Celsius
Base Info
- Model NO.：GD-12579
- Temperature Display：Digital
- Temperature Control：Low Temperature 5~99.9celsius
- Temperature Control(High Temperature)：High Temperature Ambient~99.9celsius
- Transport Package：Wooden Case for Foaming Characteristics Analyzer
- Trademark：GOLD
- Origin：China
- Production Capacity：100 Sets, Month
Description
DimensionMain unit:800mm×500mm×765mm Cooler:400mm×450mm×300mm
VI. Normal problem and solution
Warning: If there is any trouble appears, please cut off the power supply immediately. Then ask a professional to check and repair it. You can use it again only after the problem has been solved to avoid any accidents.
V. Detail Images:
V. How to order products?
---Send inquiry to us or contact with us via skype or trademanager
---Confirming the model, specification, price, qty, delivery time and payment method
---Sending invoice to customer
---Customer makes payment and send us receipt
---Arranging production
---Sending products picture to customer after the production is ready
---Shipping products to customer
VI. Contact Us:
VI. Normal problem and solution
| No | Problem | Cause | Solution |
| 1 | Power supply indication light is off | 1. no power supply 2. the fuse is damaged | 1. connect to power supply 2. change a new one |
| 2. | The heater does not work | 1. Solid relay is open circuit 2. the heater is damaged | 1. change a new one 2. change a new one |
| 3 | Temperature controller has deflection | 1.incorrect controlling temperature 2. the sensor is in trouble | 1.please to modify temperature of temperature controller 2. change a new one |
| 4 | No air flow | 1. the air pump is destroyed 2. the flow meter is unstable 3. the tube is falling | 1. change a new one 2. adjust it 3. check tube circuit to ascertain whether it is in good condition |
| 5 | The illumination light is off | The illumination light is damaged | Turn on back cover and change a new one |
