Insulating Oil Bdv Test Set, Transformer Oil Dielectric Strength Tester
Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.- Power Supply：AC 220V±10% 50,60Hz
- Output Voltage：AC 0~80kv,100kv
- Measuring Precision：3 Class
- Times：1-9
- Mixing Time：0~99 Second
- Placing Time：0-9 Minute 59second
Base Info
- Model NO.：GDYJ-501
- Environment Temperatures：5-40°c
- Relative Humidity：≤80%Rh
- Size：590*520*560mm
- Transport Package：Wooden Case Package
- Specification：53kg
- Trademark：Gold
- Origin：China
- HS Code：9031809090
- Production Capacity：1000set,Month
Description
Company.
Chongqing Gold Mechanical & Electrical Equipment Co.,Ltd is a high-tech enterprise for researching, designing, developing and producing scientific and measuring instruments. With its continuous drawing of lessonas, unremitting innovation and borrowing of advanced technology from both at home and abroad, our company is now becoming a professional manufacture of oil tester,electric tester,laboratory instrument,road building instrument and geophysical equipment.
Exhibition.
Every year we participate in the various countries of the exhibition, will recommend our products to the needs of customers around the world.We have developed sales channels in many countries such as UAE, Saudi Arabia, Iran, Malaysia, Thailand, Pakistan, India, Germany, Belgium, USA, Mexico, Kenya, Nigeria, South Africa and other countries worldwide.
And we have gained strong advantage and high reputation in international market.
Service.
1.Pre-sale Service:
Inquiry will be replied within 24 hours.
Welcome to visit our factory.
Technical datas and operation manual sent for evaluation.
2.After-sale Service:
Training how to instal the machine, training how to use the machine at our factory;
Engineers available to service machinery overseas at customers' cost;
GDYJ Series Insulating Oil Dielectric Strength Tester
Model | GDYJ-501 | GDYJ-502 | GDYJ-503 |
Output Voltage | AC 0~80KV/0~100KV | AC 0~100KV | AC 0~80KV |
Rate of Voltage Rise | 2KV/s±10% | 0.5/2/3/5 KV/s±5% | 2KV/s±10% |
Max. Time Setting | 0~9mins | 9mins | 0~99 seconds |
Test Precision | 3% RGD+0.3%FS | 3% RGD+0.3%FS | 3% RGD+0.3%FS |
Max. Data Storage | 100 groups | 100 groups | 50 groups |
Power Supply | AC220V±10% 50/60Hz | AC220V±10% 50/60Hz | AC220V±10% 50/60Hz |
Environment Temp. | 0~50Centigrade | 0~50Centigrade | 0~50Centigrade |
Related Humidity | <80%RH | <80%RH | <80%RH |
Dimension | 420*380*410mm | 620*430*330mm | 420*380*410mm |
Weight | 28kg | 41kg | 28kg |
