Automatic Capacitance Inductance Tester Three Phase of Substation Capacitor

Sansion Power Electric Co., Ltd.
  • Max Diameter of Workpiece：900mm
  • Mass Scope of Workpiece：<900kg
  • Type：Universal Testing Machine
  • Maxcapacity：<1000KN
  • Accuracy Grade：0.5
  • Load Way：Electronic Load

Base Info

  • Model NO.：SXDR-G
  • Loading Method：Dynamic Load
  • Display：LCD
  • Control：Computer Control
  • Weight：0-100Kg
  • Power Source：AC 110V,220V at Customized
  • Oil Cylinder Position：Under
  • Measuring Range：0.5UF ~ 2,000UF
  • Relative Humidity：0-90%
  • Rated Frequency：50Hz
  • Rated Output：22V,500va
  • Transport Package：Plywood Case
  • Specification：ISO9001 SGS
  • Trademark：Sansion
  • Origin：Wuhan, China
  • HS Code：9030339000
  • Production Capacity：100 Units

Description

Capacitance:
 Measuring range: 0.5μF ~ 2,000μFPower measuring range: 5 ~ 20,000kvarPrecision:±1.5% Read ±0.1μF Resolution:
0 ~ 1.999μF       ±1.0%rdG
0 ~ 19.99μF       ±1.0%rdG
0 ~ 199.9μF       ±1.0%rdG
0 ~ 1999μF        ±1.0%rdGCurrent:
 Current measuring range:
0~199.9mA
0~1.999A
0~19.99A
0~199.9A
0~1000APrecision: ±1.5%Inductance:
 Inductance measuring range:
Small inductance 1mH~10Mh
Large inductance 4 mH~10HPrecision:±(3% read±0.1mH)Resolution:   0.01mHPower supply:
 Rated voltage: power frequency 220V±10%Rated frequency: 50HzRated output: 22V/500VAWorking condition:
 Environmental temperature:
0ºC ~ +40ºCRelative humidity: ≤90%
Warranty: One year quality guarantee after shipment.

More details please kindly contact with Sansion Power.Thank you!
