• Model NO.：HYCZ-1
• Trademark：C-Tech
• Origin：China
• HS Code：90248000
• Production Capacity：1000 PCS,Year

Heating Power3000WDriving Motor Power750WElectrical supply380VSpecimen size300x300x50mm or other required  dimensionWorking Methodcrank connecting rod driven test  wheel movementRubber wheel hardness84±4   international standardTest wheel moving distance230mm±10mmLoad cycles21± 1 cycles/min, or 26.5± 1 cycles/minLoading devicethe contact pressure is 0.7±0.05Mpa when the
temperature is 60°C, total loading is around 78kg and adjustableDeformation measurement
precision0.3%Temperature control
 precision0.5°CWorking temperature0~80°C
Humidity≤90%
Donnot have corrosive and flammable gasWeight500kg approx.
