• Model NO.：JBDW-300,450,600,750C
• Power Source：AC380V
• Delivery Time：3 Days After Get Payment
• Certification：ISO Ce
• Transport Package：Standard Export Packing
• Trademark：HST
• Origin：China
• HS Code：9024101000
• Production Capacity：900 Sets Per Month

750mmImpact speed5.24 m/sRaised angle 150°Round angle of the jawR1-1.5mmRound angle of impact edgeR2-2.5mm,R8±0.05mmAngle accuracy0.1°Cooling waycompressor Capacity of sample box20Range of low temperatureroom tempeature --60°c/80°cStandard specimen dimension10mm×10(7.5/5)mm×55mmPower supply3phs, 380V, 50Hz or specified by usersNet Weight (kg)900
5. Features:
5.1 One-body cast frame design of seat and column provide high stability.
5.2 Front and rear columns are symmetrical. Pendulum arm is designed of cantilever beam support, with simple structure and high machined precision.
5.3 Apply high precision bearing with small friction. Absorbing energy without loading is less than 0.3%.
5.4 Double reduction gear system replaces old style drive system with high efficiency and avoiding transmission failure.
5.5High rigid pendulum arm prevents axial and transverse vibrations.
5.6 Exchangeable pendulum is simple to change to satisfy impact energy of 150J, 300J, 450J, 600J, 750J.
5.7 Electromagnetic release of pendulum hammer and electromagnetic clutch for locking the pendulum and raising it to its initial position. A damper is equipped to prevent strong bump when clutching.
6. Software Features:
6.1 Fully automatic, sample feeding, auto position the sample; high efficiency;
6.2 Pendulum rising, impact, sample feeding, position, free releasing is realized automatically by
   easy PC mouse click;
6.3 Safety pin guaranties the impact action, standard protection shell to avoid any accident.
6.4 Pendulum will automatically rising and ready for next impact action after specimen breakout.


Optional Equipment

Instrumented Impact System;Striker is bolted to the pendulum and available in either 8 mm (ASTM E23) or 2 mm (BS, DIN, JIS, EN,and ISO148-1983 )nose radius sizes;Anvils and pendulums for Charpy, Izod & tensile impact testing;Notch Cutter for impact specimen;Projector for verification of U and V-shaped notch of the impact specimen.
