• Model NO.：PN-CT300B
• Test Item：Rct, Ect, Fct, Pat, Cmt, CCT
• Power Supply：AC220V, 50,60Hz
• Capacity：0-3000n
• Certificate：Calibration Certificate, ISO Certificate
• Warranty：One Year
• Package Size：550*520*660mm
• Video in Youtube：HTTP:,Youtu.Be,ND3hyeecsga
• Transport Package：Wood Case, Free-Fumigation Package
• Specification：SGS, CE, ISO
• Trademark：PNSHAR
• Origin：Hangzhou, Zhejiang, China
• HS Code：90248000
• Production Capacity：300sets,Year

Basic Info.

Model NO. PN-CT300B Test Item Rct, Ect, Fct, Pat, Cmt, CCT Power Supply AC220V, 50/60Hz Capacity 0-3000n Certificate Calibration Certificate, ISO Certificate Warranty One Year Package Size 550*520*660mm Video in Youtube HTTP://Youtu.Be/ND3hyeecsga Transport Package Wood Case, Free-Fumigation Package Specification SGS, CE, ISO Trademark PNSHAR Origin Hangzhou, Zhejiang, China HS Code 90248000 Production Capacity 300sets/Year

Product Description

Automatic Paper Crush Analysis Tester

1. Description:

Automatic Paper Crush Analysis Tester is used for the test of Ring Crush Test (RCT), Edge Crush Test (ECT), Flat Crush Test (FCT), Pin Adhesion Test (PAT), Corrugating Medium Test (CMT) an Corrugated
Crush Test(CCT).

2. Applications:
Paper, Paperboard, Corrugated cardboard, Corrugated Package.

3. Standards:
ISO 3035. ISO 3037. ISO 7263.

4. Features:
1) High speed return after finishing test
2) Imported step motor with servo control adopted
3) The test result can be measured, statistical and printed automatically and the data can be saved.
4) Blue color LCD display, which can be display the crush time and loading force real time, PN-CT300B can display crush graph real time.
5) New PC software able to manage and analyse the data and can communicate with PC. (Only for PN-CT300B-PC type).
6) Built-in thermal printer
5.Specification:

NO.	ITEM	SPECIFICATION
1	Power Supply:	AC220V±10%  2A  50HZ
2	Measuring Range:	0~3000N
3	Compression Speed:	12.5 ± 2.5mm/min (0-35mm/min Can be adjusted digitally)
4	Return Velocity:	5-40.0 mm/min(Can be set randomly)
5	Display:	English menu and LCD screen
6	Printer:	thermal printing, high speed and no noise.
7	Communication output:	standard RS232 interface

6.Company Introduction:
