Slq 5ka to 25ka Primary Injection Tester for Switch and Transformer Testing
Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.- Type：Primary Injection Tester
- Maxcapacity：Na
- Accuracy Grade：0.5
- Load Way：Electronic Load
- Loading Method：Static Load
- Display：Digital
Base Info
- Model NO.：SLQ Primary Injection Tester
- Control：Manual Control
- Weight：0-100Kg
- Power Source：AC220V
- Oil Cylinder Position：Na
- Item Name：Slq 5ka to 25ka Primary Injection Tester
- Application：Test Current Load, Temperature Increase of Switch,
- Output Capacity：3kVA~150kVA
- Output Current：500A~25000A
- Apparatus：Large Current Generator, Primary Injection Test Se
- Function：Supply Large Current for Temperature Rising Test
- Structure：Seperate Structure Large Current Generator
- Test Type：5ka to 25ka Large Current Generator for Transforme
- Power Supply：220V 50Hz
- Warranty：1 Year
- Transport Package：Veneer Case
- Specification：Refer to specifications
- Trademark：GOLD
- Origin：Chongqing, China
- HS Code：9031809090
- Production Capacity：50 Sets,Month
Description
Idle current Booster Converter Current Voltage Current Voltage SLQ-3/500 3KVA 3KVA 13.6A 220V 0.5KA 6V >8% >6% SLQ -5/1000 5KVA 5KVA 22.7A 220V 1KA 5V >8% >6% SLQ -15/1000 15KVA 15KVA 68.2 220V 1KA 15V >8% >6% SLQ-10/2000 10KVA 10KVA 45.5 220V 2KA 5V >8% >6% SLQ -15/3000 15KVA 15KVA 68.2 220V 3KA 5V >8% >6% SLQ -20/4000 20KVA 20KVA 50 400V 4KA 5V >8% >6% SLQ -30/5000 30KVA 30KVA 75 400V 5KA 6V >8% >6% SLQ -28/7000 28KVA 28KVA 70 400V 7KA 4V >8% >6% SLQ -150/25000 150KVA 150KVA 375 400V 25KA 6V >8% >6% Pre-sale Service: After-sale Service:
