IEC60529 Ipx1 to Ipx6 Rain Resistance Test Chamber
Guangdong Yuanyao Test Equipment Co., Ltd.- Max Diameter of Workpiece：700mm
- Mass Scope of Workpiece：50kgs
- Type：Water Proof Test
- Maxcapacity：N,a
- Accuracy Grade：N,a
- Load Way：N,a
Base Info
- Model NO.：YSRT-1000
- Loading Method：Static Load
- Display：Digital
- Control：Manual Control
- Weight：100-500Kg
- Power Source：AC380V
- Oil Cylinder Position：N,a
- Inner Chamber Size：1000wx1000hx1000d mm
- External Chamber Size：1450wx2000hx3600d mm
- Water Drip Hole Size：0.4mm
- Rain Flow for Ipx1：1~1.5mm,Min
- Rain Flow for Ipx2：3~3.5mm,Min
- Water Flush Nozzle Size for Ipx5：6.3mm
- Water Flush Nozzle Size for Ipx6：12.5mm
- Water Drip Size：60lx60wx10h Cm
- Swing Pipe Radius：40cm
- Rotary Table Diameter：60cm
- Rotary Table Load：50kgs
- Rotary Table Rotating Speed：1~5r,Min
- Inner Chamber Material：304 Stainless Steel Plate
- External Chamber Material：Cold Rolled Sheet+Powder Coating
- Customization：Available
- Transport Package：Plywood Base Package
- Specification：CE
- Trademark：Yuanyao
- Origin：China
- HS Code：9031809090
- Production Capacity：10 Sets,Month
Description
Non-standard or special requirements are all welcome
